UVEN
LO
=
2.5 (RUVEN + 108450)
8450
UVEN
HI
= 2.5 V + (RUVEN + 100 K) (316 μA)
OV
LO
= 2.5 V + (ROV + 200 K) (348 μA)
OV
HI
=
2.5 (ROV + 206800)
6800
It is critical to keep the load current on the converter’s
input capacitor to less than 25 mA during the initial
power-up phase. This limit is set by the current limit level
and the duty cycle of the circuit breaker timer.
Once Powergood has been asserted the full load can
be enabled.
An external capacitor CE, shown in
Figures 9a and 9b
, will
provide the required UVEN hold-up filtering during the
ATCA's 5 ms, zero-volt BUS transient requirement.
Figure 8
shows the effects of CE during a BUS transient event.
Using a 2.2 μF CE capacitor and 1 mF of converter input
capacitance will enable this circuit to support a 42 W load
for the 5 ms transient. The Powergood state of the QPI-8
remains unchanged during this transient, allowing the
converter to maintain its output power to the load.
To prevent the QPI-8 from going into a fault mode and
deasserting the Powergood signal after the transient, the
converter’s input capacitors must be sized so that they can
be completely restored in the time of one 12 A current
pulse, about 1 ms, and still maintain the required input
current of the converter. If greater bulk capacitance is
required for higher loads, then the circuit in
Figure 9c
could be used to slowly charge the capacitors. To reduce
bulk capacitance and take advantage of the V
2
energy
relationship, a boost circuit with a switch-over function
can be used to charge fewer bulk storage capacitors to a
higher voltage.
Picor Corporation www.picorpower.com
QPI-8L Data Sheet Rev. 1.0 Page 4 of 8
P
P
R
R
E
E
L
L
I
I
M
M
I
I
N
N
A
A
R
R
Y
Y
Figure 8 –
5ms BUS transient, 42 W load
CH1: VBUS, CH3: PWRGD, CH4: Converter load current
0
5000
10000
15000
20000
25000
30000
Series Resistor
V
90.00
80.00
70.00
60.00
50.00
40.00
30.00
OV-HI
OV-LO
UV-HI
UV-LO
Figure 6 –
Trimming UV/OV with external series resistor.
Figure 7 –
UVEN and OV resistor equations.
