10.0 Device Pinout
10.1 Signals Overview
*: active low signal
Table 11: Signal Overview Table
Signals
Description
wrxclk, wrxclav, wrxenb*,
wrxdat, wrxsoc, wrxaddr
West Utopia L2 Receive Interface.
wtxclk, wtxclav, wtxenb*,
wtxdata, wtxsoc, wtxaddr
West Utopia L2 Transmit Interface.
wtx_err, wtx_err_stat
West Interface error indication (sampled with wtxclk).
erxclk, erxclav, erxenb*,
erxdata, erxsoc
East Utopia L1 Receive Interface.
etxclk, etxclav, etxenb*,
etxdata, etxsoc
East Utopia L1 Transmit Interface.
erx_err, erx_err_stat
East Interface error indication (sampled with wrxclk).
prty_en, cellsize, waddr
Configuration Pins to be board wired.Usual values for waddr are between
0 and 3.
reset
Active high device reset
GND
Ground
VCC
Device Power 2.5 V
clk(x)
unused clock inputs should be tied to GND
IOCTRL(x)
VCCIO(x)
IO Power 3.0 V
INREF(x)
connect to GND
PLLRST(x)
connect to GND or VCC
PLLOUT(x)
connect to GND or VCC
VCCPLL(x)
GNDPLL(x)
TCK, TRSTB
JTAG signals. connect to GND
TMS, TDI
JTAG signals. connect to VCC
TDO
JTAG signal. leave open
iov
nc
not connected. should be left open
