| 型號： | P89LPC9401FBD,557 |
| 廠商： | NXP Semiconductors |
| 文件頁數： | 37/59頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC 80C51 MCU FLASH 8K 64-LQFP |
| 標準包裝： | 450 |
| 系列： | LPC900 |
| 核心處理器： | 8051 |
| 芯體尺寸： | 8-位 |
| 速度： | 18MHz |
| 連通性： | I²C，SPI，UART/USART |
| 外圍設備： | 欠壓檢測/復位，LCD，LED，POR，PWM，WDT |
| 輸入/輸出數： | 23 |
| 程序存儲器容量： | 8KB（8K x 8） |
| 程序存儲器類型： | 閃存 |
| RAM 容量： | 256 x 8 |
| 電壓 - 電源 (Vcc/Vdd)： | 2.4 V ~ 3.6 V |
| 振蕩器型： | 內部 |
| 工作溫度： | -40°C ~ 85°C |
| 封裝/外殼： | 64-LQFP |
| 包裝： | 托盤 |
| 其它名稱： | 935278626557 |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁當前第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁
P89LPC9401_1
Koninklijke Philips Electronics N.V. 2005. All rights reserved.
Preliminary data sheet
Rev. 01 — 5 September 2005
42 of 59
Philips Semiconductors
P89LPC9401
8-bit two-clock 80C51 microcontroller with 32 segment
× 4 LCD driver
7.27.9 Power-on reset code execution
The P89LPC9401 contains two special ash elements: the Boot Vector and the Boot
Status Bit. Following reset, the P89LPC9401 examines the contents of the Boot Status
Bit. If the Boot Status Bit is set to zero, power-up execution starts at location 0000H, which
is the normal start address of the user’s application code. When the Boot Status Bit is set
to a value other than zero, the contents of the Boot Vector are used as the high byte of the
execution address and the low byte is set to 00H.
Table 9 shows the factory default Boot Vector settings for these devices. Note: These
settings are different than the original P89LPC932. Tools designed to support the
P89LPC9401 should be used to program this device, such as Flash Magic version
1.98, or later. A factory-provided boot loader is preprogrammed into the address space
indicated and uses the indicated boot loader entry point to perform ISP functions. This
code can be erased by the user. Users who wish to use this loader should take
precautions to avoid erasing the 1 kB sector that contains this boot loader. Instead,
the page erase function can be used to erase the rst eight 64-byte pages located in
this sector. A custom boot loader can be written with the Boot Vector set to the custom
boot loader, if desired.
7.27.10 Hardware activation of the boot loader
The boot loader can also be executed by forcing the device into ISP mode during a
power-on sequence (see the
P89LPC9401 User manual for specic information). This has
the same effect as having a non-zero status byte. This allows an application to be built that
will normally execute user code but can be manually forced into ISP operation. If the
factory default setting for the Boot Vector (1FH) is changed, it will no longer point to the
factory preprogrammed ISP boot loader code. After programming the ash, the status
byte should be programmed to zero in order to allow execution of the user’s application
code beginning at address 0000H.
7.28 User conguration bytes
Some user-congurable features of the P89LPC9401 must be dened at power-up and
therefore cannot be set by the program after start of execution. These features are
congured through the use of the ash byte UCFG1. Please see the
P89LPC9401 User
manual for additional details.
7.29 User sector security bytes
There are eight User Sector Security Bytes on the P89LPC9401 device. Each byte
corresponds to one sector. Please see the
P89LPC9401 User manual for additional
details.
Table 9:
Default Boot Vector values and ISP entry points
Device
Default
Boot Vector
Default
boot loader
entry point
Default boot loader
code range
1 kB sector
range
P89LPC9401
1FH
1F00H
1E00H to 1FFFH
1C00H to 1FFFH
