參數資料
型號： P89LPC9401FBD,551
廠商： NXP Semiconductors
文件頁數： 7/59頁
文件大小： 0K
描述： IC 80C51 MCU FLASH 8K 64-LQFP
標準包裝： 90
系列： LPC900
核心處理器： 8051
芯體尺寸： 8-位
速度： 18MHz
連通性： I²C，SPI，UART/USART
外圍設備： 欠壓檢測/復位，LCD，LED，POR，PWM，WDT
輸入/輸出數： 23
程序存儲器容量： 8KB（8K x 8）
程序存儲器類型： 閃存
RAM 容量： 256 x 8
電壓 - 電源 (Vcc/Vdd)： 2.4 V ~ 3.6 V
振蕩器型： 內部
工作溫度： -40°C ~ 85°C
封裝/外殼： 64-LQFP
包裝： 托盤
配用： 568-4000-ND - DEMO BOARD SPI/I2C TO DUAL UART
568-3510-ND - DEMO BOARD SPI/I2C TO UART
568-1759-ND - EMULATOR DEBUGGER/PROGRMMR LPC9X
其它名稱： 568-3227
935278626551
P89LPC9401FBD-S
xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxx x x x xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xx xx
xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxx x x
xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxx
xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx
P89LPC9401_1
K
oninklijk
e
Philips
Electronics
N.V
.2005.
All
r
ights
reser
v
ed.
Preliminar
y
data
sheet
Re
v
.01
—
5
September
2005
15
of
59
Philips
Semiconductor
s
P89LPC9401
8-bit
tw
o-c
loc
k
80C51
micr
ocontr
oller
with
32
segment
×
4
LCD
driver
[1]
BRGR1 and BRGR0 must only be written if BRGEN in BRGCON SFR is logic 0. If any are written while BRGEN = 1, the result is unpredictable.
[2]
All ports are in input only (high-impedance) state after power-up.
[3]
The RSTSRC register reects the cause of the P89LPC9401 reset. Upon a power-up reset, all reset source ags are cleared except POF and BOF; the power-on reset value is
xx11 0000.
[4]
The only reset source that affects these SFRs is power-on reset.
[5]
On power-on reset, the TRIM SFR is initialized with a factory preprogrammed value. Other resets will not cause initialization of the TRIM register.
[6]
After reset, the value is 1110 01x1, i.e., PRE2 to PRE0 are all logic 1, WDRUN = 1 and WDCLK = 1. WDTOF bit is logic 1 after watchdog reset and is logic 0 after power-on reset.
Other resets will not affect WDTOF.
TAMOD
Timer 0 and 1 auxiliary
mode
8FH
-
T1M2
-
T0M2
00
xxx0 xxx0
Bit address
8F
8E
8D
8C
8B
8A
89
88
TCON*
Timer 0 and 1 control
88H
TF1
TR1
TF0
TR0
IE1
IT1
IE0
IT0
00
0000 0000
TH0
Timer 0 high
8CH
00
0000 0000
TH1
Timer 1 high
8DH
00
0000 0000
TL0
Timer 0 low
8AH
00
0000 0000
TL1
Timer 1 low
8BH
00
0000 0000
TL2
CCU timer low
CCH
00
0000 0000
TMOD
Timer 0 and 1 mode
89H
T1GATE
T1C/T
T1M1
T1M0
T0GATE
T0C/T
T0M1
T0M0
00
0000 0000
TRIM
Internal oscillator trim
register
96H
-
ENCLK
TRIM.5
TRIM.4
TRIM.3
TRIM.2
TRIM.1
TRIM.0
WDCON
Watchdog control register
A7H
PRE2
PRE1
PRE0
-
WDRUN
WDTOF
WDCLK
WDL
Watchdog load
C1H
FF
1111 1111
WFEED1
Watchdog feed 1
C2H
WFEED2
Watchdog feed 2
C3H
Table 4:
Special function registers …continued
* indicates SFRs that are bit addressable.
Name
Description
SFR
addr.
Bit functions and addresses
Reset value
MSB
LSB
Hex
Binary
