| 型號： | P89LPC9401FBD,551 |
| 廠商： | NXP Semiconductors |
| 文件頁數： | 17/59頁 |
| 文件大小： | 0K |
| 描述： | IC 80C51 MCU FLASH 8K 64-LQFP |
| 標準包裝： | 90 |
| 系列： | LPC900 |
| 核心處理器： | 8051 |
| 芯體尺寸： | 8-位 |
| 速度： | 18MHz |
| 連通性： | I²C，SPI，UART/USART |
| 外圍設備： | 欠壓檢測/復位，LCD，LED，POR，PWM，WDT |
| 輸入/輸出數： | 23 |
| 程序存儲器容量： | 8KB（8K x 8） |
| 程序存儲器類型： | 閃存 |
| RAM 容量： | 256 x 8 |
| 電壓 - 電源 (Vcc/Vdd)： | 2.4 V ~ 3.6 V |
| 振蕩器型： | 內部 |
| 工作溫度： | -40°C ~ 85°C |
| 封裝/外殼： | 64-LQFP |
| 包裝： | 托盤 |
| 配用： | 568-4000-ND - DEMO BOARD SPI/I2C TO DUAL UART 568-3510-ND - DEMO BOARD SPI/I2C TO UART 568-1759-ND - EMULATOR DEBUGGER/PROGRMMR LPC9X |
| 其它名稱： | 568-3227 935278626551 P89LPC9401FBD-S |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁當前第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁
P89LPC9401_1
Koninklijke Philips Electronics N.V. 2005. All rights reserved.
Preliminary data sheet
Rev. 01 — 5 September 2005
24 of 59
Philips Semiconductors
P89LPC9401
8-bit two-clock 80C51 microcontroller with 32 segment
× 4 LCD driver
7.15.1 Idle mode
Idle mode leaves peripherals running in order to allow them to activate the processor
when an interrupt is generated. Any enabled interrupt source or reset may terminate Idle
mode.
7.15.2 Power-down mode
The Power-down mode stops the oscillator in order to minimize power consumption. The
P89LPC9401 exits Power-down mode via any reset, or certain interrupts. In Power-down
mode, the power supply voltage may be reduced to the data retention voltage VDDR. This
retains the RAM contents at the point where Power-down mode was entered. SFR
contents are not guaranteed after VDD has been lowered to VDDR, therefore it is highly
recommended to wake-up the processor via reset in this case. VDD must be raised to
within the operating range before the Power-down mode is exited.
Some chip functions continue to operate and draw power during Power-down mode,
increasing the total power used during power-down. These include: Brownout detect,
watchdog timer, Comparators (note that Comparators can be powered-down separately),
and RTC/System Timer. The internal RC oscillator is disabled unless both the RC
oscillator has been selected as the system clock and the RTC is enabled.
7.15.3 Total Power-down mode
This is the same as Power-down mode except that the brownout detection circuitry and
the voltage comparators are also disabled to conserve additional power. The internal RC
oscillator is disabled unless both the RC oscillator has been selected as the system clock
and the RTC is enabled. If the internal RC oscillator is used to clock the RTC during
power-down, there will be high power consumption. Please use an external low frequency
clock to achieve low power with the RTC running during power-down.
7.16 Reset
The P1.5/RST pin can function as either an active-LOW reset input or as a digital input,
P1.5. The RPE (Reset Pin Enable) bit in UCFG1, when set to logic 1, enables the external
reset input function on P1.5. When cleared, P1.5 may be used as an input pin.
Remark: During a power-up sequence, The RPE selection is overridden and this pin will
always functions as a reset input. An external circuit connected to this pin should not
hold this pin LOW during a power-on sequence as this will keep the device in reset.
After power-up this input will function either as an external reset input or as a digital input
as dened by the RPE bit. Only a power-up reset will temporarily override the selection
dened by RPE bit. Other sources of reset will not override the RPE bit.
Reset can be triggered from the following sources:
External reset pin (during power-up or if user congured via UCFG1).
Power-on detect.
Brownout detect.
Watchdog timer.
Software reset.
UART break character detect reset.
