18
64Mb: x32, 3.3V SDRAM
BatRam_3V.p65 – Rev. 0.7, Pub. 2/01
Micron Technology, Inc., reserves the right to change products or specifications without notice.
2001, Micron Technology, Inc.
64Mb: x32, 3.3V
SDRAM
PRELIMINARY
DON’T CARE
CLK
DQ
D
OUT
n
T2
T1
T4
T3
T6
T5
T0
COMMAND
ADDRESS
READ
NOP
NOP
NOP
NOP
BANK,
COL
n
NOP
D
OUT
n
+ 1
D
OUT
n
+ 2
D
OUT
n
+ 3
BURST
TERMINATE
NOP
T7
NOTE:
DQM is LOW.
CLK
DQ
D
OUT
n
T2
T1
T4
T3
T6
T5
T0
COMMAND
ADDRESS
READ
NOP
NOP
NOP
BANK,
COL
n
NOP
D
OUT
n
+ 1
D
OUT
n
+ 2
D
OUT
n
+ 3
BURST
TERMINATE
NOP
CLK
DQ
D
OUT
n
T2
T1
T4
T3
T6
T5
T0
COMMAND
ADDRESS
READ
NOP
NOP
NOP
BANK,
COL
n
NOP
D
OUT
n
+ 1
D
OUT
n
+ 2
D
OUT
n
+ 3
BURST
TERMINATE
NOP
X
= 0 cycles
CAS Latency = 1
X
= 1 cycle
CAS Latency = 2
CAS Latency = 3
X
= 2 cycles
Figure 12
Terminating A READ Burst
In the case of a fixed-length burst being executed to
completion, a PRECHARGE command issued at the
optimum time (as described above) provides the same
operation that would result from the same fixed-length
burst with auto precharge. The disadvantage of the
PRECHARGE command is that it requires that the com-
mand and address buses be available at the appropri-
ate time to issue the command; the advantage of the
PRECHARGE command is that it can be used to trun-
cate fixed-length or full-page bursts.
Full-page READ bursts can be truncated with the
BURST TERMINATE command, and fixed-length READ
bursts may be truncated with a BURST TERMINATE
command, provided that auto precharge was not acti-
vated. The BURST TERMINATE command should be
issued
x
cycles before the clock edge at which the last
desired data element is valid, where
x
equals the CAS
latency minus one. This is shown in Figure 12 for each
possible CAS latency; data element
n
+ 3 is the last
desired data element of a longer burst.
