MSP430L092
MSP430C09x
SLAS673 – SEPTEMBER 2010
www.ti.com
Reset Pin Control Register
15
14
13
12
11
10
9
8
r0
7
6
5
4
3
2
1
0
SYSRSTRE
SYSRSTUP
SYSNMIES
SYSNMI
r0
r1
rw-0
SYSRSTRE
Indicates resistor present on RST pin
SYSRSTUP
Indicates pullup on RST pin
SYSNMIES
Indicates NMI edge select
SYSNMI
NMI enable on RST/NMI pin
Memory Organization
Table 5. Memory Organization
TYPE
MSP430C091
MSP430C092
MSP430L092
MSP430L092 (EMU)(1)
32 B
Primary interrupt
ROM
vectors
0x0FFE0(2) – 0x0FFFF
Secondary
RAM
0x01C60 – 0x01C7F
interrupt vectors
Lockable
864 B
1888 B
ROM not available
Application ROM
ROM
memory
0x0FC80 – 0x0FFDF
0x0F880 – 0x0FFDF
128 B (BC)
2016 B (Loader)
Config/loading by tool
Boot Code (BC) /
ROM (by TI)
Loader Code
0x0F800 – 0x0F87F
0x0F800 – 0x0FFDF
0x0F800 – 0x0F87F
128B
128 B
RAM memory
RAM
0x02380 – 0x023FF
1792 B
1760 B
LRAM memory
RAM
(lockable)
0x01C80 – 0x0237F
0xF900 – 0xFFDF
96 B
128 B(3)
CRAM memory
RAM
(lockable)
0x01C00 – 0x01C5F
0x0F880 – 0x0F8FF
4 kB
Peripherals
Size
0x00000 – 0x00FFF
(1)
The MSP430L092 emulates the MSP430C092 device (MSP430C091 emulation via tool and software).
(2)
Not the whole interrupt vector range of CSYS is used on MSP430x09x devices (see Table 4).
(3)
Resets and interrupt redirections in RAM with alternate interrupt vectors cannot be emulated .
Start-Up Code (SUC)
The MSP430C09x start-up code checks the password and releases control to the application or enables JTAG
on password match, enters LPM4, and waits for a debug session. The behavior of the SUC is described in the
MSP430L092 Loader Code User's Guide (SLAU324).
Loader Code (Loader)
The MSP430L092 loader checks the presence of an external SPI/I2C memory device containing a valid code
signature, loads validated code into the application LRAM, and starts the application. The loader program uses
P1.2 with an external circuit to pump up the voltage required for SPI memory device readout. For complete
description of the features of the loader and its implementation, see the MSP430L092 Loader Code User's Guide
10
Copyright 2010, Texas Instruments Incorporated
