MCF51CN128 ColdFire Microcontroller Data Sheet, Rev. 4
Electrical Characteristics
Freescale Semiconductor
34
Conversion Time
(Including
sample time)
Short Sample (ADLSMP=0)
P
tADC
—
20
—
ADCK
cycles
See the ADC
chapter in the
MCF51CN128
Reference Manual
for conversion time
variances
Long Sample (ADLSMP=1)
C
—
40
—
Sample Time
Short Sample (ADLSMP=0)
P
tADS
—
3.5
—
ADCK
cycles
Long Sample (ADLSMP=1)
C
—
23.5
—
Total Unadjusted
Error
12 bit mode
T
ETUE
—
±3.0
—
LSB2
Includes
Quantization
10 bit mode
P
—
±1
±2.5
8 bit mode
T
—
±0.5
±1.0
Differential
Non-Linearity
12 bit mode
T
DNL
—
±1.75
—
LSB2
10 bit mode3
P—
±0.5
±1.0
8 bit mode3
T—
±0.3
±0.5
Integral
Non-Linearity
12 bit mode
T
INL
—
±1.5
—
LSB2
10 bit mode
P
—
±0.5
±1.0
8 bit mode
T
—
±0.3
±0.5
Zero-Scale Error 12 bit mode
T
EZS
—
±1.5
—
LSB2
VADIN = VSSAD
10 bit mode
P
—
±0.5
±1.5
8 bit mode
T
—
±0.5
Full-Scale Error
12 bit mode
T
EFS
—
±1.0
—
LSB2
VADIN = VDDAD
10 bit mode
P
—
±0.5
±1
8 bit mode
T
—
±0.5
Quantization
Error
12 bit mode
D
EQ
—-1 to 0
—
LSB2
10 bit mode
—
±0.5
8 bit mode
—
±0.5
Input Leakage
Error
12 bit mode
D
EIL
—
±2—
LSB2
Pad leakage4 *
RAS{test=pad leakage
test}
10 bit mode
—
±0.2
±4
8 bit mode
—
±0.1
±1.2
Temp Sensor
Slope
-40
°C to 25°C
D
m
—
1.646
—
mV/
°C
25
°C to 85°C
—
1.769
—
Temp Sensor
Voltage
25
°CD V
TEMP25
—701.2
—
mV
1 Typical values assume V
DDAD = 3.3 V, Temp = 25 °C, fADCK=1.0 MHz unless otherwise stated. Typical values are for reference
only and are not tested in production.
2 1 LSB = (V
REFH - VREFL)/2
N
3 Monotonicity and No-Missing-Codes guaranteed in 10 bit and 8 bit modes
4 Based on input pad leakage current. Refer to pad electricals.
Table 21. 12-bit ADC Characteristics (VREFH = VDDAD, VREFL = VSSAD) (continued)
Characteristic
Conditions
C
Symb
Min
Typ1
Max
Unit
Comment
