參數資料
型號： MC100LVEL56DWR2G
廠商： ON Semiconductor
文件頁數： 3/7頁
文件大?。?/td> 0K
描述： IC MUX 2:1 DUAL DIFF ECL 20-SOIC
標準包裝： 1,000
系列： 100LVEL
類型： 差分?jǐn)?shù)字多路復用器
電路： 2 x 2:1
獨立電路： 1
電壓電源： 雙電源
電源電壓： 3 V ~ 3.8 V
工作溫度： -40°C ~ 85°C
安裝類型： 表面貼裝
封裝/外殼： 20-SOIC（0.295"，7.50mm 寬）
供應商設備封裝： 20-SOIC
包裝： 帶卷 (TR)
MC100LVEL56
http://onsemi.com
3
Table 4. MAXIMUM RATINGS
Symbol
Parameter
Condition 1
Condition 2
Rating
Unit
VCC
PECL Mode Power Supply
VEE = 0 V
8 to 0
V
VEE
NECL Mode Power Supply
VCC = 0 V
8 to 0
V
VI
PECL Mode Input Voltage
NECL Mode Input Voltage
VEE = 0 V
VCC = 0 V
VI VCC
VI VEE
6 to 0
V
Iout
Output Current
Continuous
Surge
50
100
mA
IBB
VBB Sink/Source
± 0.5
mA
TA
Operating Temperature Range
40 to +85
°C
Tstg
Storage Temperature Range
65 to +150
°C
qJA
Thermal Resistance (JunctiontoAmbient)
0 lfpm
500 lfpm
SO20 WB
90
60
°C/W
qJC
Thermal Resistance (JunctiontoCase)
Standard Board
SO20 WB
30 to 35
°C/W
Tsol
Wave Solder
Pb
PbFree
t2 to 3 sec @ 248°C
t2 to 3 sec @ 260°C
265
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
Table 5. LVPECL DC CHARACTERISTICS VCC = 3.3 V; VEE = 0.0 V (Note 2)
Symbol
Characteristic
40°C
25°C
85°C
Unit
Min
Typ
Max
Min
Typ
Max
Min
Typ
Max
IEE
Power Supply Current
20
24
20
24
20
24
mA
VOH
Output HIGH Voltage (Note 3)
2215
2295
2420
2275
2345
2420
2275
2345
2420
mV
VOL
Output LOW Voltage (Note 3)
1470
1605
1745
1490
1595
1680
1490
1595
1680
mV
VIH
Input HIGH Voltage (SingleEnded)
2135
2420
2135
2420
2135
2420
mV
VIL
Input LOW Voltage (SingleEnded)
1490
1825
1490
1825
1490
1825
mV
VBB
Output Voltage Reference
1.92
2.04
1.92
2.04
1.92
2.04
V
VIHCMR
Input HIGH Voltage Common Mode
Range (Differential) (Note 4)
Vpp < 500 mV
Vpp y 500 mV
1.3
1.5
2.9
1.2
1.4
2.9
1.2
1.4
2.9
V
IIH
Input HIGH Current
150
mA
IIL
Input LOW Current
Dn
0.5
600
0.5
600
0.5
600
mA
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
2. Input and output parameters vary 1:1 with VCC. VEE can vary ±0.3 V.
3. Outputs are terminated through a 50 W resistor to VCC 2.0 V.
4. VIHCMR min varies 1:1 with VEE, max varies 1:1 with VCC. The VIHCMR range is referenced to the most positive side of the differential input
signal. Normal operation is obtained if the HIGH level falls within the specified range and the peak-to-peak voltage lies between VPP(min)
and 1 V.
