2
MB86603
Transfer Operation
Automatic response to selection/reselection
Prespecified receiving performed automatically at selection or reselection
Initiator: Automatically responds to reselection from target and operable until message received
Target: Automatically responds to selection from initiator and can operate until command received
Automatic receiving
Initiator: Can automatically receive information for new phase to which target shifted
Target: Can perform automatic receiving in response to attention condition generated by initiator
64-byte data register (FIFO) for data phase
Two (send-only and receive-only) 32-byte memory data buffers for message, command, and status phases
16-bit transfer block and 24-bit transfer byte registers enabling 1Tbyte transfer (1Tbyte: 16 Mbytes
Independent data transfer bus enabling microprocessor to operate during data transfer
Selection between parity through and generate
System Bus Interface
16-bit MPU/DMA stand-alone system bus
Direct connection with 68 series/80 series 16-bit MPUs
Two types of transfer
Program transfer
DMA transfer (burst mode)
Commands
Sequential command for sequential operation and programmable command for programming, including ordi-
nary commands
Command queuing
Commands can be tagged in the command phase for continuous issuing.
512-byte memory as command program memory and command queue buffer
Others
CMOS
System clock frequency: 12 MHz to 32 MHz
+5 V single power supply
SCSI-2: Enhanced Small Computer System Interface
ANSI: American National Standard Institute
SPC: SCSI-2 Protocol Controller
MPU: Micro-Processing Unit
DMA: Direct Memory Access
FIFO: First-In First-Out
ID: Identifier (identification number assigned to each device connected to SCSI bus)
80 series: General term for MPU based on command system of 8080A developed by Intel
68 series: General term for MPU developed by Motorola
×
64 Kblocks)
