MAX6406–MAX6411
Detailed Description
Manual Reset Input
Many P-based products require manual reset capabil-
ity, allowing the operator, a test technician, or external
logic circuit to initiate a reset. A logic low on MR asserts
OUT/OUT. OUT/OUT remains asserted while MR is low.
This input has an internal 50k
pullup resistor, so it can
be left open if it is not used. MR can be driven with TTL
or CMOS logic levels, or with open-drain/collector out-
puts. Connect a normally open momentary switch from
MR to GND to create a manual reset function. If MR is
driven from long cables or if the device is used in a
noisy environment, connect a 0.1F capacitor from MR
to ground to provide additional noise immunity.
Applications Information
Interfacing to Different Logic
Voltage Components
The MAX6408/MAX6411 have an active-low, open-
drain output. This output structure will sink current
when OUT is asserted. Connect a pullup resistor from
OUT to any supply voltage up to 5.5V (Figure 1). Select
a resistor value large enough to allow a valid logic low
(see Electrical Characteristics), and small enough to
register a logic high while supplying all input currents
and leakage paths connected to the OUT line.
Voltage Detectors in 4-Bump (2 X 2)
Chip-Scale Package
6
_______________________________________________________________________________________
PART
TOP MARK
PART
TOP MARK
PART
TOP MARK
MAX6406BS31-T
AEF
MAX6407BS31-T
AEP
MAX6408BS31-T
AEZ
MAX6406BS30-T
AEE
MAX6407BS30-T
AEO
MAX6408BS30-T
AEY
MAX6406BS29-T
AED
MAX6407BS29-T
AEN
MAX6408BS29-T
AEX
MAX6406BS28-T
AEC
MAX6407BS28-T
AEM
MAX6408BS28-T
AEW
MAX6406BS27-T
AEB
MAX6407BS27-T
AEL
MAX6408BS27-T
AEV
MAX6406BS26-T
AEA
MAX6407BS26-T
AEK
MAX6408BS26-T
AEU
MAX6406BS25-T
ADZ
MAX6407BS25-T
AEJ
MAX6408BS25-T
AET
MAX6406BS24-T
ADY
MAX6407BS24-T
AEI
MAX6408BS24-T
AES
MAX6406BS23-T
ADX
MAX6407BS23-T
AEH
MAX6408BS23-T
AER
MAX6406BS22-T
ADW
MAX6407BS22-T
AEG
MAX6408BS22-T
AEQ
Table 2. Device Marking Codes
PART
TOP MARK
PART
TOP MARK
PART
TOP MARK
MAX6409BS46-T
AFN
MAX6410BS46-T
AAX
MAX6411BS46-T
ABL
MAX6409BS45-T
AFM
MAX6410BS45-T
AAW
MAX6411BS45-T
ABK
MAX6409BS44-T
AFL
MAX6410BS44-T
AAV
MAX6411BS44-T
ABJ
MAX6409BS43-T
AFK
MAX6410BS43-T
AAU
MAX6411BS43-T
ABI
MAX6409BS42-T
AFJ
MAX6410BS42-T
AAT
MAX6411BS42-T
ABH
MAX6409BS41-T
AFI
MAX6410BS41-T
AAS
MAX6411BS41-T
ABG
MAX6409BS40-T
AFH
MAX6410BS40-T
AAR
MAX6411BS40-T
ABF
MAX6409BS39-T
AFG
MAX6410BS39-T
AAQ
MAX6411BS39-T
ABE
MAX6409BS38-T
AFF
MAX6410BS38-T
AAP
MAX6411BS38-T
ABD
MAX6409BS37-T
AFE
MAX6410BS37-T
AAO
MAX6411BS37-T
ABC
MAX6409BS36-T
AFD
MAX6410BS36-T
AAN
MAX6411BS36-T
ABB
MAX6409BS35-T
AFC
MAX6410BS35-T
AAM
MAX6411BS35-T
ABA
MAX6409BS34-T
AFB
MAX6410BS34-T
AAL
MAX6411BS34-T
AAZ
MAX6409BS33-T
AFA
MAX6410BS33-T
AAK
MAX6411BS33-T
AAY
