MAX6406–MAX6411
Voltage Detectors in 4-Bump (2 X 2)
Chip-Scale Package
_______________________________________________________________________________________
3
Note 1: Production testing done at +25°C only. Overtemperature limits are guaranteed by design and not production tested.
Note 2: Guaranteed by design.
ELECTRICAL CHARACTERISTICS (continued)
(VCC = 1.0V to 5.5V, TA = -40°C to +85°C, unless otherwise noted. Typical values are at VCC = 3V and TA = +25°C.) (Note1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
ISOURCE = 500A, VCC
≥ 2.1V, OUT
asserted
0.8 x VCC
VOH
ISOURCE = 50A, VCC
≥ 1.2V, OUT
asserted
0.8 x VCC
ISINK = 1.2mA, VCC
≥ 3.2V, OUT not
asserted, MAX6407 only
0.3
ISINK = 3.2mA, VCC
≥ 4.5V, OUT not
asserted, VTH
≤ 4.38V
0.4
OUT Output Voltage
(MAX6407/MAX6410)
VOL
ISINK = 3.2mA, VCC = VTH (max),
VTH
≥ 4.5V, OUT not asserted
0.4
V
Open-Drain
OUT Output
Leakage Current (Note 2)
OUT not asserted
0.1
A
Typical Operating Characteristics
(TA = +25°C, unless otherwise noted.)
0
0.3
0.2
0.1
0.5
0.4
0.9
0.8
0.7
0.6
1.0
-40
-20
0
20
40
60
80
SUPPLY CURRENT vs. TEMPERATURE
MAX6406-11
toc01
TEMPERATURE (
°C)
SUPPLY
CURRENT
(
A)
VCC = 3.3V
VCC = 5V
VCC = 1.2V
0
50
100
200
150
250
-40
-20
0
20
40
60
80
PROPAGATION DELAY (VCC FALLING)
vs. TEMPERATURE
MAX6406-11
toc02
TEMPERATURE (
°C)
PROPAGATION
DELAY
(
s)
VOD = 10mV
VOD = 20mV
VOD = 100mV
VOD = 200mV
VOD = OVERDRIVE VOLTAGE
