TEST CIRCUIT I
CC
(Opr.)
C
CP
CALCULATION
C
PD
istobe calculated withthe following formula
by using the measured value of ICC(Opr.) inthe
test circuit opposite
C
PD
=I
CC
(
Opr.
)
f
IN
x V
CC
In determining the typical value of CPD, a
relatively high frequency of 1MHz was applied to
fIN, in order to eliminate any error caused by the
quiescent supply current.
M54/M74HC242/243
6/11
