48
M37906M4C-XXXFP, M37906M4C-XXXSP, M37906M4H-XXXFP
M37906M4H-XXXSP, M37906M6C-XXXFP, M37906M6C-XXXSP
M37906M8C-XXXFP, M37906M8C-XXXSP
16-BIT CMOS MICROCOMPUTER
MITSUBISHI MICROCOMPUTERS
Fig. 52 Example waveforms in pulse mode 0
Fig. 53 Example waveforms in pulse mode 1
Pulse output port example
Pulse output port example in the case of pulse output polarity select bit = “1”
Example of pulse width modulation for above pulse output port using timer A1
Signal output each time
timer A0 becames 000016
RTP03
RTP02
RTP00
RTP01
Signal output each time
timer A0 becames 000016
RTP03
RTP02
RTP00
RTP01
Signal output each time
timer A3 becames 000016
RTP10
RTP11
Pulse output port example
Example of pulse width modulation for above pulse output port using timer A1
Signal output each time
timer A0 becames 000016
RTP11
RTP01
RTP10
RTP00
RTP02
RTP03
Signal output each time
timer A0 becames 000016
RTP11
RTP01
RTP10
RTP00
RTP02
RTP03
