MULTIJUNCTION TIMERS
10.3 TOP (Output-Related 16-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.3.3 TOP Related Register Map
Shown below is a TOP related register map.
TOP Related Register Map (1/2)
Address
+0 address
+1 address
See pages
b0
b7 b8
b15
H'0080 0240
TOP0 Counter
10-75
(TOP0CT)
H'0080 0242
TOP0 Reload Register
10-76
(TOP0RL)
H'0080 0244
(Use inhibited area)
H'0080 0246
TOP0 Correction Register
10-77
(TOP0CC)
(Use inhibited area)
H'0080 0250
TOP1 Counter
10-75
(TOP1CT)
H'0080 0252
TOP1 Reload Register
10-76
(TOP1RL)
H'0080 0254
(Use inhibited area)
H'0080 0256
TOP1 Correction Register
10-77
(TOP1CC)
(Use inhibited area)
H'0080 0260
TOP2 Counter
10-75
(TOP2CT)
H'0080 0262
TOP2 Reload Register
10-76
(TOP2RL)
H'0080 0264
(Use inhibited area)
H'0080 0266
TOP2 Correction Register
10-77
(TOP2CC)
(Use inhibited area)
H'0080 0270
TOP3 Counter
10-75
(TOP3CT)
H'0080 0272
TOP3 Reload Register
10-76
(TOP3RL)
H'0080 0274
(Use inhibited area)
H'0080 0276
TOP3 Correction Register
10-77
(TOP3CC)
(Use inhibited area)
H'0080 0280
TOP4 Counter
10-75
(TOP4CT)
H'0080 0282
TOP4 Reload Register
10-76
(TOP4RL)
H'0080 0284
(Use inhibited area)
H'0080 0286
TOP4 Correction Register
10-77
(TOP4CC)
(Use inhibited area)
H'0080 0290
TOP5 Counter
10-75
(TOP5CT)
H'0080 0292
TOP5 Reload Register
10-76
(TOP5RL)
H'0080 0294
(Use inhibited area)
H'0080 0296
TOP5 Correction Register
10-77
(TOP5CC)
H'0080 0298
(Use inhibited area)
|
