參數資料
型號: LTC3788IGN-1#PBF
廠商: LINEAR TECHNOLOGY CORP
元件分類: 穩壓器
英文描述: DUAL SWITCHING CONTROLLER, 900 kHz SWITCHING FREQ-MAX, PDSO28
封裝: 0.150 INCH, LEAD FREE, PLASTIC, SSOP-28
文件頁數: 30/30頁
文件大?。?/td> 384K
代理商: LTC3788IGN-1#PBF
LTC3788-1
9
37881fb
pin FuncTions
SENSE1, SENSE2(Pin 4, Pin 10): Negative Current
Sense Comparator Input. The (–) input to the current
comparatorisnormallyconnectedtothenegativeterminal
of a current sense resistor connected in series with the
inductor. The common mode voltage range on these pins
is 2.5V to 38V (40V abs max).
FREQ (Pin 5): The frequency control pin for the internal
VCO. Connecting the pin to GND forces the VCO to a fixed
low frequency of 350kHz. Connecting the pin to INTVCC
forces the VCO to a fixed high frequency of 535kHz. The
frequency can be programmed from 50kHz to 900kHz
by connecting a resistor from the FREQ pin to GND. The
resistor and an internal 20A source current create a volt-
age used by the internal oscillator to set the frequency.
Alternatively, this pin can be driven with a DC voltage to
vary the frequency of the internal oscillator.
PLLIN/MODE (Pin 6): External Synchronization Input
to Phase Detector and Forced Continuous Mode Input.
When an external clock is applied to this pin, it will force
the controller into forced continuous mode of operation
and the phase-locked loop will force the rising BG1 signal
to be synchronized with the rising edge of the external
clock. When not synchronizing to an external clock, this
input, which acts on both controllers, determines how
the LTC3788-1 operates at light loads. Pulling this pin to
ground selects Burst Mode operation. An internal 100k
resistortogroundalsoinvokesBurstModeoperationwhen
the pin is floated. Tying this pin to INTVCC forces continu-
ous inductor current operation. Tying this pin to a voltage
greater than 1.2V and less than INTVCC – 1.3V selects
pulse-skipping operation. This can be done by adding a
100k resistor between the PLLIN/MODE pin and INTVCC.
SGND (Pin 7): Signal Ground. All small-signal components
and compensation components should connect to this
ground, which in turn connects to PGND at a single point.
RUN1,RUN2(Pin8,Pin9):RunControlInput.Anexternal
resistor divider connects to VINandsetsthethresholdsfor
converter operation with a threshold of 1.28V. Once run-
ning,a4.5AcurrentissourcedfromtheRUNpinallowing
the user to program hysteresis using the resistor values.
INTVCC (Pin 19): Output of Internal 5.4V LDO. Power
supply for control circuits and gate drives. Decouple this
pin to GND with a minimum 4.7F low ESR tantalum or
ceramic capacitor.
EXTVCC (Pin 20): External Power Input. When this pin is
higher than 4.8V an internal switch bypasses the internal
regulatorandsupplypowertoINTVCCdirectlyfromEXTVCC.
PGND (Pin 21): Driver Power Ground. Connects to the
sources of bottom (main) N-channel MOSFETs and the
(–) terminal(s) of CIN and COUT.
VBIAS (Pin 22): Main Supply Pin. It is normally tied to the
input supply VIN or to the output of the boost converter. A
bypass capacitor should be tied between this pin and the
signal ground pin. The operating voltage range on this pin
is 4.5V to 38V (40V abs max).
BG1, BG2 (Pin 23, Pin 18): Bottom Gate. Connect to the
gate of the main NMOS.
BOOST1,BOOST2(Pin24,Pin17): Floatingpowersupply
forthesynchronousNMOS.BypasstoSWwithacapacitor
and supply with a Schottky diode connected to INTVCC.
TG1, TG2 (Pin 25, Pin 16): Top Gate. Connect to the gate
of the synchronous NMOS.
SW1, SW2 (Pin 26, Pin 15): Switch Node. Connect to the
source of the synchronous NMOS, the drain of the main
NMOS and the inductor.
PGOOD1 (Pin 27): Power Good Indicator for Channel 1.
Open-drain logic output that is pulled to ground when
the output voltage is more than ±10% away from the
regulated output voltage. To avoid false trips the output
voltage must be outside the range for 25s before this
output is activated.
SS1, SS2 (Pin 28, Pin 14): Output Soft-Start Input. A
capacitor to ground at this pin sets the ramp rate of the
output voltage during start-up.
