LTC3614
25
3614fa
Assuming worst-case conditions of VIN=2VOUT,CINshould
be selected for a maximum current rating of:
IRMS = 4A
1.8V
3.6V
3.6V
1.8V
–1
= 2ARMS
Decoupling PVIN with four 10μF to 22μF capacitors is
adequate for most applications.
If we set R2 = 196k, the value of R1 can now be determined
by solving the following equation.
R1 = 196k
1.8V
0.6V
1
A value of 392k will be selected for R1.
Finally, dene the soft start-up time choosing the proper
value for the capacitor and the resistor connected to
TRACK/SS. If we set minimum tSS = 5ms and a resistor
of 2MΩ, the following equation can be solved with the
maximum SVIN = 5.5V :
CSS =
5ms
2MΩ In
5.5V
5.5V – 0.6V
= 21.6nF
The standard value of 22nF guarantees the minimum
soft-start up time of 5ms.
Figure 1 shows the schematic for this design example.
PC Board Layout Checklist
When laying out the printed circuit board, the following
checklist should be used to ensure proper operation of
the LTC3614:
1. A ground plane is recommended. If a ground plane layer
is not used, the signal and power grounds should be
segregated with all small-signal components returning
to the SGND pin at one point which is then connected
to the PGND pin close to the LTC3614.
2. Connect the (+) terminal of the input capacitor(s), CIN,
as close as possible to the PVIN pin, and the (–) terminal
as close as possible to the exposed pad, PGND. This
capacitor provides the AC current into the internal power
MOSFETs.
3. Keep the switching node, SW, away from all sensitive
small-signal nodes.
4. Flood all unused areas on all layers with copper. Flood-
ing with copper will reduce the temperature rise of
power components. Connect the copper areas to PGND
(exposed pad) for best performance.
5. Connect the VFB pin directly to the feedback resistors.
The resistor divider must be connected between VOUT
and SGND.
APPLICATIONS INFORMATION
