LTC3609
0
3609fb
operaTion
MainControlLoop
The LTC3609 is a high efficiency monolithic synchronous,
step-down DC/DC converter utilizing a constant on-time,
current mode architecture. It operates from an input
voltage range of 4V to 32V/36V maximum and provides
a regulated output voltage at up to 6A of output current.
Theinternalsynchronouspowerswitchincreasesefficiency
and eliminates the need for an external Schottky diode. In
normal operation, the top MOSFET is turned on for a fixed
interval determined by a one-shot timer OST. When the
top MOSFET is turned off, the bottom MOSFET is turned
on until the current comparator ICMP trips, restarting the
one-shottimerandinitiatingthenextcycle.Inductorcurrent
is determined by sensing the voltage between the PGND
and SW pins using the bottom MOSFET on-resistance.
The voltage on the ITH pin sets the comparator threshold
corresponding to inductor valley current. The error ampli-
fier, EA, adjusts this voltage by comparing the feedback
signal VFB from the output voltage with an internal 0.6V
reference. If the load current increases, it causes a drop
in the feedback voltage relative to the reference. The ITH
voltage then rises until the average inductor current again
matches the load current.
At light load, the inductor current can drop to zero and
become negative. This is detected by current reversal
comparator IREV which then shuts off M2 (see Func-
tionalDiagram),resultingindiscontinuousoperation.Both
switcheswillremainoffwiththeoutputcapacitorsupplying
the load current until the ITH voltage rises above the zero
current level (0.8V) to initiate another cycle. Discontinu-
ous mode operation is disabled by comparator F when
the FCB pin is brought below 0.6V, forcing continuous
synchronous operation.
The operating frequency is determined implicitly by the
top MOSFET on-time and the duty cycle required to main-
tain regulation. The one-shot timer generates an on-time
that is proportional to the ideal duty cycle, thus holding
frequency approximately constant with changes in VIN.
The nominal frequency can be adjusted with an external
resistor, RON.
Overvoltage and undervoltage comparators OV and UV
pull the PGOOD output low if the output feedback volt-
age exits a ±10% window around the regulation point.
Furthermore, in an overvoltage condition, M1 is turned
off and M2 is turned on and held on until the overvoltage
condition clears.
Foldback current limiting is provided if the output is
shorted to ground. As VFB drops, the buffered current
threshold voltage ITHB is pulled down by clamp Q3 to
a 1V level set by Q4 and Q6. This reduces the inductor
valley current level to one sixth of its maximum value as
VFB approaches 0V.
Pulling the RUN/SS pin low forces the controller into its
shutdown state, turning off both M1 and M2. Releasing
the pin allows an internal 1.2A current source to charge
up an external soft-start capacitor, CSS. When this voltage
reaches 1.5V, the controller turns on and begins switching,
but with the ITH voltage clamped at approximately 0.6V
below the RUN/SS voltage. As CSS continues to charge,
the soft-start current limit is removed.
INTVCC/EXTVCCPower
PowerforthetopandbottomMOSFETdriversandmostof
the internal controller circuitry is derived from the INTVCC
pin. The top MOSFET driver is powered from a floating
bootstrap capacitor, CB.Thiscapacitorisrechargedfrom
INTVCC through an external Schottky diode, DB, when
the top MOSFET is turned off. When the EXTVCC pin is
grounded, an internal 5V low dropout regulator supplies
the INTVCC power from VIN. If EXTVCC rises above 4.7V,
the internal regulator is turned off, and an internal switch
connects EXTVCC to INTVCC. This allows a high efficiency
source connected to EXTVCC, such as an external 5V sup-
ply or a secondary output from the converter, to provide
the INTVCC power. Voltages up to 7V can be applied to
EXTVCC for additional gate drive. If the input voltage is
low and INTVCC drops below 3.5V, undervoltage lockout
circuitry prevents the power switches from turning on.
