LTC3542
16
3542fa
Linear Technology Corporation
1630 McCarthy Blvd., Milpitas, CA 95035-7417
(408) 432-1900 ● FAX: (408) 434-0507 ● www.linear.com
LINEAR TECHNOLOGY CORPORATION 2006
LT 0907 REV A PRINTED IN USA
PART NUMBER
DESCRIPTION
COMMENTS
LTC3405/LTC3405B
300mA IOUT, 1.5MHz, Synchronous Step-Down DC/DC
Converter
95% Efciency, VIN: 2.5V to 5.5V, VOUT(MIN) = 0.8V, IQ = 20μA,
ISD < 1μA, ThinSOT Package
LTC3406/LTC3406B
600mA IOUT, 1.5MHz, Synchronous Step-Down DC/DC
Converter
96% Efciency, VIN: 2.5V to 5.5V, VOUT(MIN) = 0.6V, IQ = 20μA,
ISD < 1μA, ThinSOT Package
LTC3407/LTC3407-2
Dual 600mA/800mA IOUT, 1.5MHz/2.25MHz, Synchronous
Step-Down DC/DC Converter
95% Efciency, VIN: 2.5V to 5.5V, VOUT(MIN) = 0.6V, IQ = 40μA,
ISD < 1μA, MS10E, DFN Packages
LTC3409
600mA IOUT, 1.7MHz/2.6MHZ, Synchronous Step-Down
DC/DC Converter
96% Efciency, VIN: 1.6V to 5.5V, VOUT(MIN) = 0.6V, IQ = 65μA,
ISD < 1μA, DFN Package
LTC3410/LTC3410B
300mA IOUT, 2.25MHz, Synchronous Step-Down DC/DC
Converter
95% Efciency, VIN: 2.5V to 5.5V, VOUT(MIN) = 0.8V, IQ = 26μA,
ISD < 1μA, SC70 Package
LTC3411
1.25A IOUT, 4MHz, Synchronous Step-Down DC/DC
Converter
95% Efciency, VIN: 2.5V to 5.5V, VOUT(MIN) = 0.8V, IQ = 60μA,
ISD < 1μA, MS10, DFN Packages
LTC3548
Dual 400mA/800mA IOUT, 2.25MHz, Synchronous
Step-Down DC/DC Converter
95% Efciency, VIN: 2.5V to 5.5V, VOUT(MIN) = 0.6V, IQ = 40μA,
ISD < 1μA, MS10, DFN Packages
LTC3561
1A IOUT, 4MHz Synchronous Step-Down DC/DC Converter 95% Efciency, VIN: 2.6V to 5.5V, VOUT(MIN) = 0.8V, IQ = 240μA,
ISD < 1μA, 3mm × 3mm DFN Package
Using Low Prole Components, <1mm Height
VIN
LTC3542
RUN
75k
*TDK VLF3010AT-2R2MIR0
**TDK C2012X5R0J106M
3542 TA02a
150k
22pF
2.2
mH*
CIN**
10
mF
CER
COUT**
10
mF
CER
SW
2
6
4
1
3
5
VIN
2.7V TO 5.5V
VOUT
1.5V
500mA
VFB
MODE/SYNC
GND
Efciency vs Output Current
OUTPUT CURRENT (mA)
30
EFFICIENCY
(%)
90
100
20
10
80
50
70
60
40
0.1
10
100
1000
3542 TA02b
0
1
VIN = 3.6V
VOUT = 1.5V
Burst Mode OPERATION
TYPICAL APPLICATION
RELATED PARTS
