LT3511
16
3511fb
DESIGN PROCEDURE/DESIGN EXAMPLE
Use the following design procedure as a guide to design-
ing applications for the LT3511. Remember, the unique
sampling architecture requires an iterative process for
choosing correct resistor values.
The design example involves designing a 15V output with
a 100mA load current and an input range from 36V to 72V.
VIN(MIN) = 36V, VIN(NOM) = 48V, VIN(MAX) = 72V, VOUT =
15V and IOUT = 100mA
Step 1: Select the transformer turns ratio.
NPS <
VSW(MAX) – VIN(MAX) – VLEAKAGE
VOUT + VF
VSW(MAX) = Max rating of internal switch = 150V
VLEAKAGE = Margin for transformer leakage spike = 40V
VF = Forward voltage of output diode = assume approxi-
mately ~ 0.5V
Example:
NPS <
150V – 72V – 40V
15V + 0.5V
NPS < 2.45
NPS = 2
The choice of turns ratio is critical in determining output
power as shown earlier in the Output Power section. At
this point, a third winding can be added to the transformer
to drive the BIAS pin of the LT3511 for higher efficiencies.
Choose a turns ratio that sets the third winding voltage
to regulate between 3.3V and 6V for maximum efficiency.
Choose a third winding ratio to drive BIAS winding with
5V. (Optional)
Example:
NTHIRD
NS
= VTHIRD
VOUT
= 5V
15V
= 0.33
The turns ratio of the transformer chosen is as follows
NPRIMARY: NSECONDARY: NTHIRD = 2:1:0.33.
Step 2: Calculate maximum power output at minimum
VIN.
POUT(VIN(MIN)) = η VIN(MIN) IIN = η VIN(MIN) D
IPEAK 0.5
D =
VOUT + VF
(
) NPS
VOUT + VF
(
) NPS + VIN(MIN)
η = Efficiency = ~75%
IPEAK = Peak switch current = 0.26A
Example:
D = 0.46
POUT(VIN(MIN)) = 1.62
IOUT(VIN(MIN)) = POUT(VIN(MIN))/VOUT = 0.11A
The chosen turns ratio satisfies the output current re-
quirement of 100mA. If the output current was too low,
the minimum input voltage could be adjusted higher. The
turns ratio in this example is set to its highest ratio given
switch voltage requirements and margin for leakage in-
ductance voltage spike.
Step 3: Determine primary inductance, switching fre-
quency and saturation current.
Primary inductance for the transformer must be set above
a minimum value to satisfy the minimum off and on time
requirements.
LPRI ≥
tOFF(MIN) NPS VOUT + VF
(
)
IPEAK(MIN)
tOFF(MIN) = 400ns
IPEAK(MIN) = 55mA
LPRI ≥
tON(MIN) VIN(MAX)
IPEAK(MIN)
tON(MIN) = 100ns
IPEAK(MIN) = 55mA
applicaTions inForMaTion
