Application Information
(Continued)
Rail-to-Rail Input Low Power ComparatorsD
Push-Pull Output
LMC7211
LMC6762
Tiny, SOT23-5, DIP
SO-8, DIP
Single
Dual
Open Drain Output
LMC7221
LMC6772
Tiny, SOT23-5, DIP
SO-8, DIP
Single
Dual
9.0 Additional SOT23-5 Tiny
Devices
National Semiconductor has additional parts available in the
space saving SOT23 Tiny package, including amplifiers,
voltage references, and voltage regulators. These devices
includeD
LMC7101
1 MHz gain-bandwidth rail-to-rail input and out-
put amplifierDhigh input impedance and high
gain 700
m
A typical current 2.7V, 3V, 5V and 15V
specifications.
LMC7111
Low power 50 kHz gain-bandwidth rail-to-rail in-
put and output amplifier with 25
m
A typical cur-
rent specified at 2.7V, 3.0V, 3.3V, 5V and 10V.
LM7131
Tiny Video amp with 70 MHz gain bandwidth 3V,
5V and
g
5V specifications.
Micropower SOT 50 mA Ultra Low-Dropout Reg-
ulator.
LP2980
LM4040
Precision micropower shunt voltage reference.
Fixed voltages of 2.500V, 4.096V, 5.000V,
8.192V and 10.000V.
LM4041
Precision micropower shut voltage reference
1.225V and adjustable.
Contact your National Semiconductor representative for the
latest information.
10.0 Spice Macromodel
A Spice Macromodel is available for the LMC7211 compara-
tor on the National Semiconductor Amplifier Macromodel
disk. Contact your National Semiconductor representative
to obtain the latest version.
REEL DIMENSIONS
TL/H/12337–13
8 mm
7.00
330.00
0.059 0.512 0.795 2.165 0.331
a
0.059/
b
0.000 0.567 W1
a
0.078/
b
0.039
1.50
13.00 20.20 55.00
8.40
a
1.50/
b
0.00
14.40
W1
a
2.00/
b
1.00
Tape Size
A
B
C
D
N
W1
W2
W3
10
