April 2001
FDS6678A
30V N-Channel PowerTrench
MOSFET
2001 Fairchild Semiconductor Corporation
FDS6678A Rev C(W)
General Description
This
specifically to improve the overall efficiency of DC/DC
converters using either synchronous or conventional
switching PWM controllers. It has been optimized for
low gate charge, low R
DS(ON)
and fast switching speed.
N-Channel
MOSFET
has
been
designed
Applications
DC/DC converter
Features
7.5 A, 30 V.
R
DS(ON)
= 24 m
@ V
GS
= 4.5 V
R
DS(ON)
= 20 m
@ V
GS
= 10 V
High performance trench technology for extremely
low R
DS(ON)
Low gate charge (13 nC typical)
High power and current handling capability
S
D
S
S
SO-8
D
D
D
G
4
3
2
1
5
6
7
8
Absolute Maximum Ratings
T
A
=25
o
C unless otherwise noted
Symbol
Parameter
V
DSS
Drain-Source Voltage
V
GSS
Gate-Source Voltage
I
D
Drain Current – Continuous
– Pulsed
Power Dissipation for Single Operation
T
J
, T
STG
Operating and Storage Junction Temperature Range
Ratings
30
±
12
7.5
40
2.5
1.2
1.0
-55 to +150
Units
V
V
A
W
(Note 1a)
(Note 1a)
(Note 1b)
P
D
(Note 1c)
°
C
Thermal Characteristics
R
θ
JA
Thermal Resistance, Junction-to-Ambient
R
θ
JC
Thermal Resistance, Junction-to-Case
(Note 1a)
50
25
°
C/W
°
C/W
(Note 1)
Package Marking and Ordering Information
Device Marking
Device
FDS6678A
FDS6678A
Reel Size
13’’
Tape width
12mm
Quantity
2500 units
F
