FN3116.9
DG406, DG407
Single 16-Channel/Differential 8-Channel,
CMOS Analog Multiplexers
The DG406 and DG407 monolithic CMOS analog
multiplexers are drop-in replacements for the popular
DG506A and DG507A series devices. They each include an
array of sixteen analog switches, a TTL and CMOS
compatible digital decode circuit for channel selection, a
voltage reference for logic thresholds, and an ENABLE input
for device selection when several multiplexers are present.
These multiplexers feature lower signal ON resistance
(<100
) and faster transition time (t
TRANS
< 300ns)
compared to the DG506A and DG507A. Charge injection
has been reduced, simplifying sample and hold applications.
The improvements in the DG406 series are made possible
by using a high voltage silicon-gate process. An epitaxial
layer prevents the latch-up associated with older CMOS
technologies. The 44V maximum voltage range permits
controlling 30V
P-P
signals when operating with
±
15V power
supplies.
The sixteen switches are bilateral, equally matched for AC or
bidirectional signals. The ON resistance variation with
analog signals is quite low over a
±
5V analog input range.
Pinouts
Features
ON-Resistance (Max). . . . . . . . . . . . . . . . . . . . . . . . 100
Low Power Consumption (P
D
) . . . . . . . . . . . . . . . <1.2mW
Fast Transition Time (Max). . . . . . . . . . . . . . . . . . . . 300ns
Low Charge Injection
TTL, CMOS Compatible
Single or Split Supply Operation
Pb-Free Plus Anneal Available (RoHS Compliant)
Applications
Battery Operated Systems
Data Acquisition
Medical Instrumentation
Hi-Rel Systems
Communication Systems
Automatic Test Equipment
Related Literature
Technical Brief TB363 “Guidelines for Handling and
Processing Moisture Sensitive Surface Mount Devices
(SMDs)”
V+
NC
NC
S
16
S
15
S
14
S
13
S
12
S
11
S
10
S
9
GND
NC
A
3
D
S
8
S
7
S
6
S
5
S
4
S
3
S
2
S
1
EN
A
0
A
1
A
2
V-
28
27
26
25
24
23
22
21
20
19
18
17
16
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
V+
D
B
NC
S
8B
S
7B
S
6B
S
5B
S
4B
S
3B
S
2B
S
1B
GND
NC
NC
D
A
V-
S
8A
S
7A
S
6A
S
5A
S
4A
S
3A
S
2A
S
1A
EN
A
0
A
1
A
2
28
27
26
25
24
23
22
21
20
19
18
17
16
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
DG406 (PDIP, SOIC)
TOP VIEW
DG407 (PDIP, SOIC)
TOP VIEW
Ordering Information
PART
NUMBER
PART
MARKING
TEMP.
RANGE (°C)
PACKAGE
PKG.
DWG. #
DG406DJ
DG406DJ
-40 to 85
28 Ld PDIP
E28.6
DG406DJZ
(See Note)
DG406DJZ
-40 to 85
28 Ld PDIP*
(Pb-free)
E28.6
DG406DY
DG406DY
-40 to 85
28 Ld SOIC
M28.3
DG406DY-T
DG406DY
28 Ld SOIC Tape and Reel M28.3
DG406DYZ
(See Note)
DG406DYZ
-40 to 85
28 Ld SOIC
(Pb-free)
M28.3
DG406DYZ-T
(See Note)
DG406DYZ 28 Ld SOIC Tape and Reel
(Pb-free)
M28.3
DG407DJ
DG407DJ
-40 to 85
28 Ld PDIP
E28.6
DG407DJZ
(Note)
DG407DJZ
-40 to 85
28 Ld PDIP*
(Pb-free)
E28.6
DG407DY
DG407DY
-40 to 85
28 Ld SOIC
M28.3
DG407DYZ
(Note)
DG407DYZ
-40 to 85
28 Ld SOIC
(Pb-free)
M28.3
*Pb-free PDIPs can be used for through hole wave solder processing only. They are
not intended for use in Reflow solder processing applications.
NOTE: Intersil Pb-free plus anneal products employ special Pb-free material sets;
molding compounds/die attach materials and 100% matte tin plate termination
finish, which are RoHS compliant and compatible with both SnPb and Pb-free
soldering operations. Intersil Pb-free products are MSL classified at Pb-free peak
reflow temperatures that meet or exceed the Pb-free requirements of IPC/JEDEC J
STD-020.
