參數資料
型號： ATF1508BE-5AX100
廠商： Atmel
文件頁數： 2/30頁
文件大?。?/td> 0K
描述： IC CPLD 128MC 1.8V ISP 100TQFP
標準包裝： 90
系列： ATF15xx
可編程類型： 系統內可編程（最少 10,000 次編程/擦除循環）
最大延遲時間 tpd(1)： 7.0ns
電壓電源 - 內部： 1.7 V ~ 1.9 V
宏單元數： 128
輸入/輸出數： 80
工作溫度： 0°C ~ 70°C
安裝類型： 表面貼裝
封裝/外殼： 100-TQFP
供應商設備封裝： 100-TQFP（14x14）
包裝： 托盤
10
3663A–PLD–1/08
ATF1508BE
3.
Power Management
Unlike conventional CPLDs with sense amplifiers, the ATF1508BE is designed using low-power
full CMOS design techniques. This enables the ATF1508BE to achieve extremely low power
consumption over the full operating frequency spectrum.
The ATF1508BE also has an optional power-down mode. In this mode, current drops to below
100 A. When the power-down option is selected, either PD1 or PD2 pins (or both) can be used
to power down the part. When enabled, the device goes into power-down when either PD1 or
PD2 is high. In the power-down mode, all internal logic signals are latched and held, as are any
enabled outputs.
All pin transitions are ignored until the PD pin is brought low. When the power-down feature is
enabled, the PD1 or PD2 pin cannot be used as a logic input or output. However, the pin’s mac-
rocell may still be used to generate buried foldback and cascade logic signals.
All power-down AC characteristic parameters are computed from external input or I/O pins.
4.
Security Feature
A fuse is provided to prevent unauthorized copying of the ATF1508BE fuse patterns. Once
enabled, fuse reading or verification is inhibited. However, the 16-bit User Electronic Signature
remains accessible. To reset this feature, the entire memory array in the device must be erased.
5.
Programming Methods
The ATF1508BE devices are In-System Programmable (ISP) or In-System Configurable (ISC)
devices utilizing the 4-pin JTAG protocol. This capability eliminates package handling normally
required for programming and facilitates rapid design iterations and field changes.
When using the ISP hardware or software to program the ATF1508BE devices, four I/O pins
must be reserved for the JTAG interface. However, the logic features that the macrocells have
associated with these I/O pins are still available to the design for buried logic functions.
To facilitate ISP programming by the Automated Test Equipment (ATE) vendors, Serial Vector
Format (SVF) files can be created by Atmel-provided software utilities. ATF1508BE devices can
also be programmed using standard third-party programmers. With a third-party programmer,
the JTAG ISP port can be disabled, thereby allowing four additional I/O pins to be used for logic.
The ATF1508BE device supports several configuration modes which gives designers several
unique options for programming.
The different modes of programming are:
ISC – In-System Configuration
OTF – On-the-Fly Reconfiguration
DRA – Direct Reconfiguration Access
