Test Circuits
(Continued)
TL/H/10409–9
FIGURE 3. Linearity/Acquisition Time/
Conversion Time Test Circuit
TL/H/10409–10
FIGURE 4. Static Measurements
Functional Description
This Analog to Digital Converter is a single-slope 8-bit,
6-channel A/D converter that provides all of the necessary
analog functions for a microprocessor-based data/control
system. The device uses the processor system to provide
the necessary addressing, timing and counting functions
and includes a 1-of-8 decoder, 8-channel analog multiplex-
er, sample and hold, precision current reference, ramp inte-
grator and comparator on a single monolithic chip.
Applications that require auto-zero or auto-calibration, (See
Figures 5–8) can use selection of address 000 and 111, for
input address lines A0–A2, in conjunction with the arithme-
tic capability of a microprocessor to provide ground and
scaling factors. Address 0, 0, 0 internally connects the input
of the ramp generator to ground and may be used for zero
offset correction in subsequent conversions. Address 1, 1,
1, internally connects the input of the ramp generator to the
voltage reference, V
REF
, and may be used for scale factor
correction in subsequent conversions. For the following, re-
fer to the Functional Block Diagram.
Six separate external analog voltage inputs may come into
terminals I1–I6 and the specific analog input to be convert-
ed is selected via address terminals A0–A2. The analog
input voltage level is transferred to the external ramp capac-
itor connected to pin 4 when the input to the ramp start
terminal (pin 3) is at a logic 0 (See Figure 1). The time to
charge the capacitor is the acquisition time which is a func-
tion of the output impedance of an amplifier internal to the
A/D converter and the value of the capacitor. After charging
the external capacitor the ramp start terminal is switched to
a logic 1 which introduces a high impedance between the
analog input voltage and the external capacitor.
The capacitor begins to discharge at a controlled rate. The
controlled rate of discharge (ramp) is established by the ex-
ternal reference voltage, the external reference resistor, the
value of the external capacitor and the internal leakage of
the A/D converter. Connected to the capacitor terminal is a
comparator internal to the A/D converter with its output go-
ing to the ramp stop terminal (pin 7). The comparator output
is a logic one when the capacitor is charged and switches to
a logic 0 when the capacitor is in a discharged state. The
ramp time is from the time when ramp start goes HIGH (log-
ic ‘‘1’’) to when ramp stop goes LOW (logic ‘‘0’’). The micro-
processor must be programmed to determine this conver-
sion time. The ideal (no undesirable internal source imped-
ances, leakage paths, errors on levels where comparator
switches or delay time) conversion time is calculated as fol-
lows:
Ramp Time
e
V1C
H
I
R
Where
V1
e
Analog Input Voltage Being Measured
C
H
e
External Ramp Capacitor
I
R
e
V
CC
b
V
REF
R
REF
V
CC
e
Power Supply Voltage
V
REF
e
Reference Voltage
R
REF
e
Reference Resistor
In actual use the errors due to a nonideal A/D converter can
be minimized by using a microprocessor to make the calcu-
lations. (See Figures 5 through 8.)
Where
Channel Selection
Input Address Line
Selected
Analog Input
A2
A1
A0
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
Ground
I1
I2
I3
I4
I5
I6
V
REF
4
