| 型號： | 74ALVCH16543DGG:11 |
| 廠商： | NXP Semiconductors |
| 文件頁數： | 8/20頁 |
| 文件大小： | 0K |
| 描述： | IC TRANSCVR TRI-ST 16BIT 56SSOP |
| 產品培訓模塊： | Logic Packages |
| 標準包裝： | 35 |
| 系列： | 74ALVCH |
| 邏輯類型： | 寄存收發器，非反相 |
| 元件數： | 2 |
| 每個元件的位元數： | 8 |
| 輸出電流高，低： | 24mA，24mA |
| 電源電壓： | 1.2 V ~ 3.6 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 56-TFSOP（0.240"，6.10mm 寬） |
| 供應商設備封裝： | 56-TSSOP |
| 包裝： | 管件 |
| 其它名稱： | 74ALVCH16543DG 74ALVCH16543DG-ND 935262544112 |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁當前第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁
1999 Nov 23
16
Philips Semiconductors
Product specication
16-bit D-type registered transceiver; 3-state
74ALVCH16543
Suitability of surface mount IC packages for wave and reow soldering methods
Notes
1. All surface mount (SMD) packages are moisture sensitive. Depending upon the moisture content, the maximum
temperature (with respect to time) and body size of the package, there is a risk that internal or external package
cracks may occur due to vaporization of the moisture in them (the so called popcorn effect). For details, refer to the
Drypack information in the
“Data Handbook IC26; Integrated Circuit Packages; Section: Packing Methods”.
2. These packages are not suitable for wave soldering as a solder joint between the printed-circuit board and heatsink
(at bottom version) can not be achieved, and as solder may stick to the heatsink (on top version).
3. If wave soldering is considered, then the package must be placed at a 45
° angle to the solder wave direction.
The package footprint must incorporate solder thieves downstream and at the side corners.
4. Wave soldering is only suitable for LQFP, TQFP and QFP packages with a pitch (e) equal to or larger than 0.8 mm;
it is definitely not suitable for packages with a pitch (e) equal to or smaller than 0.65 mm.
5. Wave soldering is only suitable for SSOP and TSSOP packages with a pitch (e) equal to or larger than 0.65 mm; it is
definitely not suitable for packages with a pitch (e) equal to or smaller than 0.5 mm.
DEFINITIONS
LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.
PACKAGE
SOLDERING METHOD
WAVE
REFLOW(1)
BGA, SQFP
not suitable
suitable
HLQFP, HSQFP, HSOP, HTSSOP, SMS
not suitable(2)
suitable
PLCC(3), SO, SOJ
suitable
LQFP, QFP, TQFP
not recommended(3)(4)
suitable
SSOP, TSSOP, VSO
not recommended(5)
suitable
Data sheet status
Objective specication
This data sheet contains target or goal specications for product development.
Preliminary specication
This data sheet contains preliminary data; supplementary data may be published later.
Product specication
This data sheet contains nal product specications.
Limiting values
Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specication
is not implied. Exposure to limiting values for extended periods may affect device reliability.
Application information
Where application information is given, it is advisory and does not form part of the specication.
