MAX4711/MAX4712/MAX4713
Fault-Protected, Low-Voltage,
Quad SPST Analog Switches
_______________________________________________________________________________________
7
ELECTRICAL CHARACTERISTICS—+3V Single Supply (continued)
(V+ = +2.7V to +3.6V, V- = 0, VIH = +2.0V, VIL = +0.6V, GND = 0, TA = TMIN to TMAX, unless otherwise noted. Typical values are at
TA = +25°C.) (Note 3)
PARAMETER
SYMBOL
CONDITIONS
TA
MIN
TYP
MAX
UNITS
LOGIC INPUT
Input Logic High
VIH
C, E
2
V
Input Logic Low
VIL
C, E
0.6
V
Input-Leakage Current (Note 5)
IIN_VIN_ = 0 or V+
C, E
-5
+5
A
SWITCH DYNAMICS
+25°C
340
500
Turn-On Time
tON
V+ = +2.7V, VNO_ or VNC_ = +1.5V,
RL = 300, CL = 35pF, Figure 2
C, E
600
ns
+25°C
100
175
Turn-Off Time
tOFF
V+ = +2.7V, VNO_ or VNC_ = +1.5V,
RL = 300, CL = 35pF, Figure 2
C, E
225
ns
+25°C
60
240
Break-Before-Make Time Delay
(MAX4713 only)
tBBM
V+ = +2.7V, VNO_ or VNC_ = +1.5V,
RL = 300, CL = 35pF, Figure 2
C, E
50
ns
POWER SUPPLY
Power-Supply Range
V+
C, E
2.7
11
V
+25°C
815
V+ Supply Current
I+
All VIN_ = 0 or V+
C, E
20
A
Note 3: Algebraic convention is used in this data sheet; the most negative value is shown in the minimum column.
Note 4: RON = RON(MAX) - RON(MIN)
Note 5: Leakage parameters are 100% tested at maximum-rated temperature and with dual supplies. Leakage parameters are
guaranteed by correlation at +25°C.
Note 6: Off-isolation = 20 log10 [VCOM_/(VNO_ or VNC_)], VCOM_ = output, VNO_ or VNC_ = input to off switch.
Note 7: Between any two switches.
