85322AMI
www.icst.com/products/hiperclocks.html
REV. B OCTOBER 7, 2003
9
Integrated
Circuit
Systems, Inc.
ICS85322I
D
UAL
LVCMOS / LVTTL-
TO
-D
IFFERENTIAL
2.5V / 3.3V LVPECL T
RANSLATOR
3. Calculations and Equations.
The purpose of this section is to derive the power dissipated into the load.
LVPECL output driver circuit and termination are shown in Figure 3.
T
o calculate worst case power dissipation into the load, use the following equations which assume a 50
load, and a termination
voltage of V
CC
- 2V.
For logic high, V
OUT
= V
OH_MAX
=
V
CC_MAX
– 1.0V
(V
CC_MAX
- V
OH_MAX
) =
1.0V
For logic low, V
OUT
= V
OL_MAX
=
V
CC_MAX
– 1.7V
(V
CC_MAX
- V
OL_MAX
) =
1.7V
Pd_H is power dissipation when the output drives high.
Pd_L is the power dissipation when the output drives low.
Pd_H = [(V
OH_MAX
– (V
CC_MAX
- 2V))/R
[(2V - 1V)/50
L
] * (V
CC_MAX
- V
OH_MAX
) = [(2V - (V
CC_MAX
- V
OH_MAX
))/R
L
] * (V
CC_MAX
- V
OH_MAX
) =
Pd_L = [(V
OL_MAX
– (V
CC_MAX
- 2V))/R
[(2V - 1.7V)/50
] * 1.7V =
10.2mW
L
] * (V
CC_MAX
- V
OL_MAX
) = [(2V - (V
CC_MAX
- V
OL_MAX
))/R
L
] * (V
CC_MAX
- V
OL_MAX
) =
Total Power Dissipation per output pair = Pd_H + Pd_L =
30.2mW
F
IGURE
3. LVPECL D
RIVER
C
IRCUIT
AND
T
ERMINATION
Q1
V
OUT
V
CC
RL
50
V
CC
- 2V
