參數資料
型號： 5322AMI
英文描述： DUAL LVCMOS / LVTTL-TO-DIFFERENTIAL 2.5V / 3.3V LVPECL TRANSLATOR
中文描述： 雙的LVCMOS / LVTTL至差分為2.5V / 3.3V的LVPECL的譯者
文件頁數： 7/13頁
文件大?。?/td> 160K
代理商： 5322AMI
85322AMI
www.icst.com/products/hiperclocks.html
REV. B OCTOBER 7, 2003
7
Integrated
Circuit
Systems, Inc.
ICS85322I
D
UAL
LVCMOS / LVTTL-
TO
-D
IFFERENTIAL
2.5V / 3.3V LVPECL T
RANSLATOR
T
ERMINATION
FOR
2.5V LVPECL O
UTPUT
Figure 2Aand Figure 2Bshow examples of termination for 2.5V
LVPECL driver. These terminations are equivalent to terminat-
ing 50
to V
CC
- 2V. For V
CC
= 2.5V, the V
CC
- 2V is very close to
ground level. The R3 in Figure 2B can be eliminated and the
termination is shown in Figure 2C.
F
IGURE
2C. 2.5V LVPECL T
ERMINATION
E
XAMPLE
R2
50
Zo = 50 Ohm
VCCO=2.5V
R1
50
Zo = 50 Ohm
+
-
2.5V
2,5V LVPECL
Driver
F
IGURE
2B. 2.5V LVPECL D
RIVER
T
ERMINATION
E
XAMPLE
VCCO=2.5V
R1
50
R2
50
Zo = 50 Ohm
R3
18
2,5V LVPECL
Driver
Zo = 50 Ohm
+
-
2.5V
F
IGURE
2A. 2.5V LVPECL D
RIVER
T
ERMINATION
E
XAMPLE
R2
62.5
2.5V
2,5V LVPECL
Driver
R3
250
Zo = 50 Ohm
Zo = 50 Ohm
R4
62.5
2.5V
+
-
R1
250
VCCO=2.5V
