TECHNICAL DATA SHEET
RPC-2.40
PANEL PLUG
09S421-271S3
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
1 / 2
R
F
_
3
5
/1
2
.0
4
/3
.0
All dimensions are in mm; tolerances according to ISO 2768 m-H
Interface
Mechanically compatible with
RPC-1.85
Documents
Assembly instruction
02 A3
Panel piercing
B 55
Material and plating
Connector parts
Material
Plating
Center contact
Beryllium copper Gold, min. 1.27 m, over chemical nickel
Outer contact
Stainless steel
Passivated
Coupling nut
Stainless steel
Passivated
Dielectric
PEEK
Solder sleeve
Brass
Gold, 0.1 m min.
