Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | TOP 1.5GS/5.08 | TOP
1.5GS/90-5.08
- 3 -
UL 1059 rating data
Rated voltage (Use group D)
300 V
Rated current (Use group D)
10 A
AWG conductor, min.
26
AWG conductor, max.
14
Approvals
Approvals institutes
Downloads
CAD Library (P-CAD Format - Standard)
TOP 1.5GS.LIB
Classifications
ETIM 2.0
NK
ETIM 3.0
EC001284
eClass 4.1
NK
eClass 5.0
NK
eClass 5.1
NK
Similar products
Order No.
Part designation
Version
0641960000
TOP1.5GS2/90 5 2STI OR
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm, Pitch: 5.08 mm, No. of poles: 2, 90°, Box
0642060000
TOP1.5GS3/90 5 2STI OR
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm, Pitch: 5.08 mm, No. of poles: 3, 90°, Box
0642160000
TOP1.5GS/04/90
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm, Pitch: 5.08 mm, No. of poles: 4, 90°, Box
1578820000
TOP1.5GS5/90 5 2STI OR
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm, Pitch: 5.08 mm, No. of poles: 5, 90°, Box
0593860000
TOP1.5GS6/90 5 2STI OR
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm, Pitch: 5.08 mm, No. of poles: 6, 90°, Box
0593960000
TOP1.5GS7/90 5 2STI OR
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm, Pitch: 5.08 mm, No. of poles: 7, 90°, Box
0594060000
TOP1.5GS8/90 5 2STI OR
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 2.5 mm, Pitch: 5.08 mm, No. of poles: 8, 90°, Box
