參數資料
| 型號： | 0642260000 |
| 廠商： | WEIDMULLER |
| 元件分類： | 接線盒 |
| 英文描述： | 24 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 2/4頁 |
| 文件大小： | 96K |
| 代理商： | 0642260000 |
Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | TOP 1.5GS/5.08 | TOP
1.5GS/90-5.08
- 2 -
Material data
Insulating material
PA
Colour
orange
colour chart
Similar to RAL 2000
Insulating material group
I
Flammability class UL 94
V-2
CTI
>= 600
Contact base material
CuZn
Contact surface
tinned
Storage temperature, min.
-25 °C
Storage temperature, max.
55 °C
Connectable conductors
Clamping range, min.
0.13 mm
Clamping range, max.
2.5 mm
AWG, min.
26
AWG, max.
14
Solid, min. H05(07) V-U
0.5 mm
Solid, max. H05(07) V-U
2.5 mm
Flexible, min. H05(07) V-K
0.5 mm
Flexible, max. H05(07) V-K
2.5 mm
With wire end ferrule, acc. to DIN 46 228/1, min.
0.5 mm
With wire end ferrule, acc. to DIN 46 228/1, max. 2.5 mm
w. plastic collar ferrule, DIN 46228 pt 4, min.
0.5 mm
w. plastic collar ferrule, DIN 46228 pt 4, max.
2.5 mm
Gauge to EN 60999 a x b;
2.4 mm x 1.5 mm;
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
24 A
Rated current, max. No. pins (Tu=20°C)
19 A
Rated current, min. No. pins(Tu=40°C)
21
Rated current, max. No. pins (Tu=40°C)
16 A
Rated voltage for overvoltage class/pollution
severity II/2
630 V
Rated voltage for overvoltage class/pollution
severity III/2
320 V
Rated voltage for overvoltage class/pollution
severity III/3
250 V
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
2.5 kV
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
2.5 kV
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
2.5 kV
Short-time withstand current resistance
3 x 1s with 120 A
CSA rating data
Rated voltage (Use group D)
300 V
Rated current (Use group D)
10 A
AWG conductor (field wiring), min.
26
AWG conductor (field wiring), max.
14
