79
μ
PD753036
Debugging tool
The in-circuit emulators (IE-75000-R and IE-75001-R) are available as the program debugging tool for the
μ
PD753036.
The system configurations are described as follows.
Hardware
IE-75000-R
Note 1
In-circuit emulator for debugging the hardware and software when developing the
application systems that use the 75X series and 75XL series. When developing a
μ
PD753036 subseries, the emulation board IE-75300-R-EM and emulation probe
EP-75336GC-R or EP-75336GK-R that are sold separately must be used with the
IE-75000-R.
By connecting with the host machine and the PROM programmer, efficient debugging
can be made.
It contains the emulation board IE-75000-R-EM which is connected.
IE-75001-R
In-circuit emulator for debugging the hardware and software when developing the
application systems that use the 75X series and 75XL series. When developing a
μ
PD753036 sub-series, the emulation board IE-75300-R-EM and emulation probe
EP-75336GC-R or EP-75336GK-R which are sold separately must be used with the
IE-75001-R.
It can debug the system efficiently by connecting the host machine and PROM program-
mer.
IE-75300-R-EM
Emulation board for evaluating the application systems that use the
μ
PD753036
subseries.
It must be used with the IE-75000-R or IE-75001-R.
EP-75336GC-R
Emulation probe for the
μ
PD753036GC.
It must be connected to IE-75000-R (or IE-75001-R) and IE-75300-R-EM.
It is supplied with the 80-pin conversion socket EV-9200GC-80 which facilitates
connection to a target system.
EV-9200GC-80
EP-75336GK-R
Emulation probe for the
μ
PD753036GK.
It must be connected to the IE-75000-R (or IE-75001-R) and IE-75300-R-EM.
It is supplied with the 80-pin conversion adapter TGK-080SDW which facilitates
connection to a target system.
TGK-080SDW
Note 2
Software
IE control program
Connects the IE-75000-R or IE-75001-R to a host machine via RS-232-C and
Centronics I/F and controls the above hardware on a host machine.
Host machine
Part number
(product name)
OS
Distribution media
PC-9800 series
MS-DOS
3.5-inch 2HD
μ
S5A13IE75X
Ver. 3.30 to
5-inch 2HD
μ
S5A10IE75X
Ver. 6.2
Note 3
IBM PC/AT compatible
machines
Refer to
“
OS for IBM PC
”
3.5-inch 2HC
μ
S7B13IE75X
5-inch 2HC
μ
S7B10IE75X
Notes 1.
Maintenance parts
This is a product of Tokyo Eletech Corp. (03-5295-1661).
When purchasing this product, consult your NEC distributor.
Ver.5.00 and the upper versions of Ver.5.00 have the task swap function, but it cannot be used for
this software.
2.
3.
Remarks 1.
The operation of the IE control program is guaranteed only on the above host machines and OSs.
The
μ
PD753036 subseries consists of the
μ
PD753036 and 75P3036.
2.
