Data Sheet U14388EJ2V0DS00
39
μ
PD31172
4. RECOMMENDED SOLDERING CONDITIONS
The
μ
PD31172 should be soldered and mounted under the following recommended conditions.
For the details of the recommended soldering conditions, refer to the document
Semiconductor Device
Mounting Technology Manual (C10535E)
.
For soldering methods and conditions other than those recommended below, contact your NEC sales
representative.
Table 4-1. Surface Mounting Type Soldering Conditions
Soldering Method
Soldering Conditions
Recommended
Condition
Symbol
Infrared reflow
Package peak temperature: 235°C, Time: 30 seconds max. (at 210°C or higher),
Count: Three times or less, Exposure limit: 7 days
10 to 72 hours)
Note
(after that, prebake at 125°C for
IR35-107-3
VPS
Package peak temperature: 215°C, Time: 25 to 40 seconds (at 200°C or higher),
Count: Three times or less, Exposure limit: 7 days
10 to 72 hours)
Note
(after that, prebake at 125°C for
VP15-107-3
Partial heating
Pin temperature: 300°C max., Time: 3 seconds max. (per pin row)
–
Note
After opening the dry pack, store it at 25°C or less and 65% RH or less for the allowable storage period.
Caution
Do not use different soldering methods together (except for partial heating).
