POWER-DOWN CONTROL MODE
The
μ
PB1009K consists of an RF block, an IF block, and a PLL block. By controlling reduction of power to each block (by
applying a voltage to the PD1 and PD2 pins), the following four modes can be used.
Test Conditions
Mode
No.
Mode Name
PD1
PD2
RF Block
IF Block
(IF + ADC)
PLL Block
1
Active mode
L
H
ON
ON
ON
2
Calibration mode
H
H
OFF
ON
ON
3
Warm-up mode
H
L
OFF
OFF
ON
4
Sleep mode
L
L
OFF
OFF
OFF
Caution To use only the active mode and sleep mode, fix PD1 to L and select the desired mode with PD2.
REFERENCE CLOCK CONTROL MODE
The divided frequency can be selected as follows so that it can be shared with the TCXO of each system.
Test Conditions
TCXO Frequency
PD1
PD2
1/N
Phase Comparison Frequency
16.368 MHz (GPS)
16.384 MHz (GPS)
L
L
1/100
16.368 MHz
16.384 MHz
19.2 MHz (W-CDMA)
L
H
3/256
19.2 MHz
14.4 MHz (PDC)
H
L
9/1024
14.4 MHz
26 MHz (GSM)
H
H
65/4096
26 MHz
Caution When the reference clock frequency is 16.368 MHz, the 1stIF frequency and 2ndIF frequency are 61.38
MHz and 4.092 MHz, respectively. They are respectively 62.98 MHz and 2.556 MHz in all other cases.
