PM-134
U
Description
Miniature size and rugged construction
Designed for high shock environments
Suited for IR and vapor reflow solder
Frequency range 1kHz to 2MHz
Ferrite core material
Applications
Computer, pager and battery powered equipment
Environmental Data
Storage temperature range: -40°C to +125°C
Operating ambient temperature range: -40°C to +85°C
range is application specific.Temperature rise is
approximately 40°C at rated RMS current.Maximum
operating temperature is 125°C including ambient.
Solder reflow temperature:+260°C max.for 10 seconds
max.
Packaging
Supplied in tape and reel packaging, 2,500 per reel
Part
Number
Inductance
μH
(Rated)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
27
33
39
47
68
100
OCL (1)
μH ± 20%
Irms (2)
Amperes
Isat (3)
Amperes
DCR (4)
Ohms
(Max)
0.030
0.034
0.050
0.060
0.088
0.128
0.156
0.250
0.360
0.480
0.560
0.650
0.820
1.10
1.58
UP0.4C-1R0-R
UP0.4C-1R5-R
UP0.4C-2R2-R
UP0.4C-3R3-R
UP0.4C-4R7-R
UP0.4C-6R8-R
UP0.4C-100-R
UP0.4C-150-R
UP0.4C-220-R
UP0.4C-270-R
UP0.4C-330-R
UP0.4C-390-R
UP0.4C-470-R
UP0.4C-680-R
UP0.4C-101-R
1.16
1.49
2.27
3.22
4.95
7.06
9.53
14.5
21.8
27.5
32.2
39.0
46.5
68.2
102.5
2.88
2.58
2.15
1.89
1.55
1.30
1.16
0.95
0.76
0.69
0.64
0.59
0.53
0.45
0.37
3.33
2.94
2.38
2.00
1.61
1.35
1.16
0.94
0.77
0.68
0.63
0.57
0.53
0.43
0.35
UNI-PAC 0.4C
Low Cost, Low Profile
Power Inductors (Surface Mount)
1) Open Circuit Inductance Test Parameters: 100kHz, 0.250 Vrms, 0.0 Adc
2) RMS current, delta temp.of 40°C ambient temperature of 85°C
3) Peak current for approximately 30% roll-off @ 20°C
4) Values @ 20°C
Mechanical Diagrams
TOP VIEW
4.45
max
2.40
max
4.45
ref
1.00 ref
(2x)
1
y
x
2
FRONT VIEW
2.92
max
6.60
max
RECOMMENDED PCB LAYOUT
4.06
COMPONENT VIEW
2.9
(2x)
1.4 (2x)
SCHEMATIC
2
1
Dimensions in Millimeters.
yww = Date Code xxx = Inductance value per family chart
0%
20%
40%
60%
80%
100%
0%
20%
40%
60%
80% 100% 120% 140% 160%
% of Isat
%
Inductance
Characteristics
20RoHS
