1997 Mar 07
2
Philips Semiconductors
Product specification
1.3 GHz bidirectional I
2
C-bus controlled
synthesizer
TSA5518M
FEATURES
Complete 1.3 GHz single chip system
Low power 5 V, 40 mA
I
2
C-bus programming
One pin crystal oscillator
In-lock flag
Varicap drive disable
Low radiation
Address selection for picture in picture (PIP), DBS tuner,
and so on
5-level A/D converter
7 bus-controlled ports (4 open-collector outputs and
3 emitter follower outputs), 1 bidirectional port
Power-down flag
Mixer/oscillator bandswitch output
Available in SSOP20 package.
APPLICATIONS
TV tuners and front-ends
VCR tuners.
GENERAL DESCRIPTION
The device is a single chip PLL frequency synthesizer
designed for TV tuning systems. Control data is entered
via the I
2
C-bus; five serial bytes are required to address
the device, select the oscillator frequency, program the
7 output ports and set the charge-pump current.
The output port P6 is combined with an A/D converter
input. Digital information concerning this port can be read
out of the SDA line (one status byte) during a READ
operation. A flag is set when the loop is ‘in-lock’ and is read
during a READ operation. The device has one fixed
I
2
C-bus address, programmed by applying a specific
voltage on AS input. The phase comparator operates at
7.8125 kHz when a 4 MHz crystal in used. The device
provides a bandswitch output to select the bands of the
mixer/oscillator ICs TDA5330, TDA5630A except
TDA5630/C1 and TDA5730 with the appropriate voltage
level.
QUICK REFERENCE DATA
ORDERING INFORMATION
SYMBOL
V
CC
I
CC
f
i
V
i(rms)
PARAMETER
CONDITIONS
MIN.
4.5
80
12
9
40
3.2
10
TYP.
5
40
4
MAX.
5.5
1300
300
300
300
4.48
5
20
10
+80
120
UNIT
V
mA
MHz
mV
mV
mV
MHz
mA
mA
mA
°
C
K/W
supply voltage
supply current
frequency
input voltage level (RMS value)
80 to 150 MHz
150 MHz to 1.0 GHz
1 GHz to 1.3 GHz
f
xtal
I
o
crystal oscillator frequency
output current
emitter follower on P4, P5 and P7
open-collector P0, P1 and P2
open-collector P6
T
amb
R
th j-a
operating ambient temperature
thermal resistance from
junction to ambient
TYPE
NUMBER
PACKAGE
NAME
DESCRIPTION
VERSION
TSA5518M
SSOP20
plastic shrink small outline package; 20 leads; body width 4.4 mm
SOT266-1
