| 型號： | TS3V712ELRTGR |
| 廠商： | TEXAS INSTRUMENTS INC |
| 元件分類： | 多路復用及模擬開關 |
| 英文描述： | 7-CHANNEL, VIDEO MULTIPLEXER, PQCC32 |
| 封裝： | GREEN, PLASTIC, MO-220, WQFN-32 |
| 文件頁數： | 20/20頁 |
| 文件大小： | 579K |
| 代理商： | TS3V712ELRTGR |
CL
(see Note A)
TEST CIRCUIT
S1
2 × VDD
Open
GND
RL
NOTES: A. CL includes probe and jig capacitance.
B. Waveform 1 is for an output with internal conditions such that the output is low
, except when disabled by the output control.
Waveform 2 is for an output with internal conditions such that the output is high, except when disabled by the output control.
C. All input pulses are supplied by generators having the following characteristics: PRR
≤ 10 MHz, ZO = 50 , tr ≤ 2.5 ns, tf ≤ 2.5 ns.
D. The outputs are measured one at a time, with one transition per measurement.
E. tPLZ and tPHZ are the same as tdis.
F. tPZL and tPZH are the same as ten.
50
VG1
VDD
DUT
50
VIN
50
VG2
50
VI
Input Generator
VO
tPZL
VOH -10%
VOLTAGE WAVEFORMS
ENABLE AND DISABLE TIMES
VDD/2
Output Control
(VIN)
VOH
VOL +10%
VOH
VOL
0 V
tPZH
tPLZ
tPHZ
Output
Waveform 2
S1 at GND
(see Note B)
Output
Waveform 1
S1 at 2 x VDD
(see Note B)
VOL
VO
VI
VO
VDD/2
VDD
RL
S1
V
CL
VDD
Vin
3.3 V± 0.3 V
2 × VDD
200
or
1 k*
GND
10 pF
0.3 V
GND
VDD
10 pF
0.3 V
3.3 V± 0.3 V
TEST
tPLZ/tPZL
tPHZ/tPZH
VDD_5
5 V± 0.5 V
R = 200
applies to all switch outputs
R = 1 k
applies to all buffer outputs
L
*
www.ti.com
SCDS303A – AUGUST 2010 – REVISED SEPTEMBER 2010
PARAMETER MEASUREMENT INFORMATION
(Enable and Disable Times)
Figure 9. Test Circuit and Voltage Waveforms
Copyright 2010, Texas Instruments Incorporated
9
Product Folder Link(s): TS3V712EL
