TPA032D03
10W MONO CLASSD AUDIO POWER AMPLIFIER
SLOS283B DECEMBER 1999 REVISED JUNE 2000
4
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
Class-D amplifier faults
Table 1. Class-D Amplifier Fault Table
FAULT 0
FAULT 1
DESCRIPTION
1
No fault. The device is operating normally.
0
1
Charge pump under-voltage lock-out (VCP-UV) fault. All low-side transistors are turned on, shorting the load to
ground. Once the charge pump voltage is restored, normal operation resumes, but FAULT1 is still active. This is not
a latched fault, however. FAULT1 is cleared by cycling MUTE, SHUTDOWN, or the power supply.
0
Thermal fault. All the low-side transistors are turned on, shorting the load to ground. Once the junction temperature
drops 20
°C, normal operation resumes (not a latched fault). But the FAULTx terminals are still set and are cleared
by cycling MUTE, SHUTDOWN, or the power supply.
headphone amplifier faults
The thermal fault remains active when the device is in head phone mode. This fault operation has exactly the
same as it does for the Class-D amplifier (see Table 1).
If HPVCC drops below approximately 4.5 V, the head phone is disabled. Once HPVCC exceeds approximately
4.5 V, the head phone amplifier is re-enabled. No fault is reported to the user.
AVAILABLE OPTIONS
PACKAGED DEVICES
TA
TSSOP
(DCA)
40
°C to 125°C
TPA032D03DCA
The DCA package is available in left-ended tape and reel. To order
a taped and reeled part, add the suffix R to the part number (e.g.,
TPA032D03DCAR).
相關PDF資料
PDF描述
TPA032D04DCAR 10 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO48
TPA032D04DCA 10 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO48
TPA032D04DCAG4 10 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO48
TPA032D04DCARG4 10 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO48
TPA102DGNR 0.07 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO8
相關代理商/技術參數
參數描述
TPA032D03EVM 制造商:Texas Instruments 功能描述:TPA032D03 CLASS-D AUDIO POWER AMO EVM - Bulk
TPA032D04 制造商:TI 制造商全稱:Texas Instruments 功能描述:10-W STEREO CLASS-D AUDIO POWER AMPLIFIER
TPA032D04_07 制造商:TI 制造商全稱:Texas Instruments 功能描述:10-W STEREO CLASS-D AUDIO POWER AMPLIFIER
TPA032D04DCA 功能描述:音頻放大器 10W Stereo RoHS:否 制造商:STMicroelectronics 產品:General Purpose Audio Amplifiers 輸出類型:Digital 輸出功率: THD + 噪聲: 工作電源電壓:3.3 V 電源電流: 最大功率耗散: 最大工作溫度: 安裝風格:SMD/SMT 封裝 / 箱體:TQFP-64 封裝:Reel
TPA032D04DCAG4 功能描述:音頻放大器 Stereo Medium Pwr Class-D Aud Amp RoHS:否 制造商:STMicroelectronics 產品:General Purpose Audio Amplifiers 輸出類型:Digital 輸出功率: THD + 噪聲: 工作電源電壓:3.3 V 電源電流: 最大功率耗散: 最大工作溫度: 安裝風格:SMD/SMT 封裝 / 箱體:TQFP-64 封裝:Reel
