參數資料
型號： TNC-J-P-H-RA-TH1
廠商： SAMTEC INC
元件分類： RF連接器
英文描述： BOARD TERMINATED, FEMALE, TNC CONNECTOR, SOLDER, JACK
封裝： ROHS COMPLIANT
文件頁數： 1/1頁
文件大?。?/td> 192K
代理商： TNC-J-P-H-RA-TH1
DESIGNED & DIMENSIONED
IN MILLIMETERS[INCHES]
-H: HEAVY GOLD
-TH1: THROUGH HOLE
-RA: RIGHT ANGLE
-P: PCB
-J: JACK
TERMINATION
ORIENTATION
PLATING
TYPE
GENDER
TNC-J-P-X-RA-TH1
2.00 .079
(4 PLCS)
9.65 .380
9.65 .380
1.10 .043
RECOMMENDED PCB LAYOUT
18.00
REF
.709
11.00
REF
.433
12.50
REF
.492
3.00
REF
.118
DO NOT
SCALE FROM
THIS PRINT
"A"
"A"
'B'
9.68
REF
.381
31.10
REF
1.224
11.00
REF
.433
9.65
REF
.380
(4 PLCS)
25.60
REF
1.008
THIS PRODUCT MANUFACTURED
WITH LEAD-FREE PROCESSING
Pb
7/16-28 UNEF-2A
(REF)
1.00
REF
.039
3.45 .136
TO CENTER CONTACT
2.80
REF
.110
3.30 .130
TO INSULATOR
SECTION "A"-"A"
SHELL
(TNC-J-P-X-RA-TH1-SHL)
SOCKET
(TNC-J-P-X-RA-TH1-SKT)
BODY
(TNC-J-P-X-RA-TH1-BDY)
INSULATOR
(TNC-J-P-RA-TH1-INS1)
RING
(BTNC-RNG-001-X)
INSULATOR
(TNC-J-P-RA-TH1-INS)
C2
SEE NOTE 4
1.13 .044
(2 PLCS)
(REF)
DETAIL 'B'
SCALE 4 : 1
C1
SHEET OF
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN MILLIMETERS [INCHES]
TOLERANCES ARE:
DECIMALS ANGLES
.X:
0.3 [.01] 2
.XX:
0.13 [.005]
.XXX:
0.051 [.0020]
MATERIAL:
SHELL, BODY, RING: BRASS
SOCKET: COPPER ALLOY
DIELECTRIC: PTFE
BY:
TNC-J-P-X-RA-TH1
DWG. NO.
DESCRIPTION:
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
DO NOT SCALE DRAWING
R MUSSER
12/20/2007
1
SHEET SCALE: 2:1
REVISION C
F:\DWG\SW\EXISPROD\ASSEMBLY\RF\Tnc\Tnc-j-p-x-ra-th1\TNC-J-P-X-RA-TH1-ASM.SLDDRW
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733 FAX: 812-948-5047
e-Mail: info@SAMTEC.com code: 55322
NOTES:
1. REPRESENTS A CRITICAL DIMENSION.
2. PRODUCT TO BE PACKAGED PER PACKAGING STANDARD CO-HD-WI-3040-M.
3. RoHs COMPLIANT.
4. APPLY LOCKING ADHESIVE TO THREADS OF BODY AND SHELL AT ASSEMBLY.
5. PLATING: -H: .000030" MIN. GOLD OVER .000050" MIN. NICKEL.
-N: .000100" MIN. NICKEL.
6. ASSEMBLY PLATING DESIGNATIONS:
-H: (CENTER CONTACT) -H
(OUTER CONTACT) -N
(REMAINING METAL PARTS) -N.
