參數資料
型號： TC9462F
元件分類： 消費家電
英文描述： SPECIALTY CONSUMER CIRCUIT, PQFP100
封裝： 14 X 20 MM, 0.65 MM PITCH, PLASTIC, QFP-100
文件頁數： 15/17頁
文件大?。?/td> 226K
代理商： TC9462F
TC9462F
2001-11-05
7
Electrical Characteristics
(unless otherwise specified, VDD
==== AVDD ==== DVDD ==== XVDD ==== 5 V, 2VREF ==== P2VREF ==== 4.2 V,
VREF
==== PVREF ==== 2.1 V, Ta ==== 25°C)
DC Characteristics
Characteristics
Symbol
Test
Circuit
Test Condition
Min
Typ.
Max
Unit
Assured supply voltage
VDD
Ta
= -40~85°C
4.5
5.0
5.5
V
Normal
speed
45
50
60
Assured supply current
IDD
4 times
speed
XI
=
16.9344 MHz
50
55
65
mA
“H” Level
VIH
3.5
Input voltage
“L” Level
VIL
CMOS input terminal
(except analog input)
1.5
V
“H” Level
IIH
VIH = 5 V
1.0
Input current
“L” Level
IIL
VIL = 0 V
CMOS Input
Terminal
(except analog
input)
-1.0
mA
“H” Level
ITLH
VIH = 5 V
0.1
Tri-state
leak current
“L” Level
ITLL
VIL = 0 V
following (1)
-0.1
mA
“H” Level
IOH (1)
VOH = 4.6 V
-1.0
“L” Level
IOL (1)
VOL = 0.4 V
following (1)
(except TMAXS,
TMAX)
2.0
“H” Level
IOH (2)
VOH = 4.6 V
-1.0
“L” Level
IOL (2)
VOH = 0.4 V
following (2)
2.0
“H” Level
IOH (3)
VOH = 4.6 V
-1.4
-0.6
“L” Level
IOL (3)
VOL = 0.4 V
following (3)
0.6
1.4
“H” Level
IOH (4)
VOH = 3.8 V
-1.0
Output current
“L” Level
IOL (4)
VOL = 0.4 V
following (4)
2.0
mA
VREF output ON resistor
RON
following (4)
(except TMAXS, TMAX)
500
W
Pull-up resistor
RUP
following (5)
25.0
50.0
75.0
k
W
Osc. Amp. feedback resistor
RN
between XI-XO and PXI-PXO
terminal
1.0
2.0
3.0
M
W
Terminal Name
(1) Terminal
HSO
, UHSO , EMPH, DOUT, MBOV, IPF, SBOK, CLCK, TESIO1
DATA, SFSY, SBSY, SPCK, MONIT, TESIO0, TMAXS, TMAX, SEL
FLGA, FLGB, FLGC, FLGD, IO0, IO1, IO2, IO3
(2) Terminal
LRCK, BCK, AOUT, SPDA, COFS, ZDET
(3) Terminal
BUS0~3
(4) Terminal
PDO, TMAXS, TMAX, RFGC, TEBC, FMO, FVO, DMO
(5) Terminal
DMOUT
, CKSE , DACT , TSMOD, RST , TEST0~4
相關PDF資料
PDF描述
TC9464FN SERIAL INPUT LOADING, 1-BIT DAC, PDSO24
TC9465F SPECIALTY CONSUMER CIRCUIT, PQFP44
TC9470FN SERIAL, PARALLEL, WORD INPUT LOADING, 1-BIT DAC, PDSO24
TC9472F SPECIALTY CONSUMER CIRCUIT, PQFP100
TC9482F 6 CHANNEL(S), VOLUME CONTROL CIRCUIT, PDSO28
相關代理商/技術參數
參數描述
TC9462F_01 制造商:TOSHIBA 制造商全稱:Toshiba Semiconductor 功能描述:Digital Servo Single Chip Processor
TC9464FN 制造商:TOSHIBA 制造商全稱:Toshiba Semiconductor 功能描述:TOSHIBA CMOS DIGITAL INTEGRATED CIRCUIT SILICON MONOLITHIC
TC9465F 制造商:TOSHIBA 制造商全稱:Toshiba Semiconductor 功能描述:SINGLE CHIP KARAOKE LSI
TC9470FN 制造商:TOSHIBA 制造商全稱:Toshiba Semiconductor 功能描述:?-? Modulation DA Converter with Built-in 8-Times Oversampling Digital Filter/Dynamic Digital Bass Boost/Analog Filter
TC9482F 制造商:TOSHIBA 制造商全稱:Toshiba Semiconductor 功能描述:CMOS DIGITAL INTEGRATED CIRCUIT SILICON MONOLITHIC
