4-11
TELCOM SEMICONDUCTOR, INC.
7
6
5
4
3
1
2
8
TC660
100mA CHARGE PUMP DC-TO-DC
VOLTAGE CONVERTER
clock frequency using TTL logic, the addition of a 10k
pull-
up resistor to V
+
supply is required. Note that the pump
frequency with external clocking, as with internal clocking,
will be 1/2 of the clock frequency. Output transitions occur on
the positive-going edge of the clock.
It is also possible to increase the conversion efficiency
of the TC660 at low load levels by lowering the oscillator
frequency. This reduces the switching losses, and is achieved
by connecting an additional capacitor, C
OSC
, as shown in
Figure 7. Lowering the oscillator frequency will cause an
undesirable increase in the impedance of the pump (C
1
) and
the reservoir (C
2
) capacitors. To overcome this, increase the
values of C
1
and C
2
by the same factor that the frequency
has been reduced. For example, the addition of a 100pF
capacitor between pin 7 (OSC) and GND will lower the
oscillator frequency to 1kHz from its nominal frequency of
10kHz (a multiple of 10), and necessitate a corresponding
increase in the values of C
1
and C
2
.
Positive Voltage Doubler
Figure 5. Increased Output Voltage by Cascading Devices
1
2
3
4
8
7
6
5
V+
1
2
3
4
8
7
6
5
150
μ
F
150
μ
F
150
μ
F
"n"
"1"
150
μ
F
VOUT
. VOUT= –n(V+) for 1.5V
≤
V+
≤
5.5V
NOTE:
*
*
+
+
+
+
TC660
TC660
Figure 6. External Clocking
1
2
3
4
8
7
6
5
TC660
+
V+
+
CMOS
GATE
150
μ
F
VOUT
150
μ
F
OSC
V+
Cascading Devices
The TC660 may be cascaded as shown (Figure 5) to
produce larger negative multiplication of the initial supply
voltage. However, due to the finite efficiency of each device,
the practical limit is 10 devices for light loads. The output
voltage is defined by:
V
OUT
= –n (V
IN
)
where n is an integer representing the number of devices
cascaded. The resulting output resistance would be ap-
proximately the weighted sum of the individual TC660 R
OUT
values.
Changing the TC660 Oscillator Frequency
It may be desirable in some applications (due to noise or
other considerations) to increase the oscillator frequency.
Pin 1, the FC pin, may be connected to V
+
to increase
oscillator frequency to 90kHz from a nominal of 10 kHz for
an input supply voltage of 5.0 volts. The oscillator may also
be synchronized to an external clock as shown in Figure 6
and LV must be grounded when overdriving OSC. In a
situation where the designer has generated the external
Figure 7. Lowering Oscillator Frequency
1
2
3
4
8
7
6
5
+
V+
VOUT
C1
COSC
+
C2
TC660
