參數資料
| 型號： | SY898535XLKY |
| 廠商： | Micrel Inc |
| 文件頁數： | 4/7頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC CLOCK BUFFER MUX 2:4 20-TSSOP |
| 標準包裝： | 74 |
| 系列： | Precision Edge® |
| 類型： | 扇出緩沖器（分配），多路復用器 |
| 電路數： | 1 |
| 比率 - 輸入:輸出： | 2:4 |
| 差分 - 輸入:輸出： | 無/是 |
| 輸入： | LVCMOS，LVTTL，晶體 |
| 輸出： | LVPECL |
| 頻率 - 最大： | 235MHz |
| 電源電壓： | 3.135 V ~ 3.465 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 20-TSSOP（0.173"，4.40mm 寬） |
| 供應商設備封裝： | 20-TSSOP |
| 包裝： | 管件 |
| 其它名稱： | 576-3931 |
Micrel, Inc.
SY898535XL
June 2011
4
M9999-062211-B
hbwhelp@micrel.com or (408) 955-1690
Absolute Maximum Ratings
(1)
Supply Voltage (VCC).................................... –0.5V to +4.6V
Input Voltage (VIN)..................................–0.5V to VCC +0.5V
LVPECL Output Current (IOUT) .............................................
Continuous............................................................50mA
Surge ..................................................................100mA
Lead Temperature (soldering, 20 sec.).................... +260°C
Storage Temperature (Ts) ........................... –65°C to 150°C
Operating Ratings
(2)
Supply Voltage (VCC)............................ +3.135V to +3.465V
Ambient Temperature (TA) ...........................-40°C to +85°C
Package Thermal Resistance
(3)
TSSOP (
θ JA)
Still-Air......................................................73.2°C/W
Power Supply DC Electrical Characteristics
(4)
VCC = 3.3V ±5%; TA = -40°C to +85°C, unless otherwise stated.
Symbol
Parameter
Condition
Min
Typ
Max
Units
VCC
Power Supply
3.135
3.3
3.465
V
IEE
Power Supply Current
No load, max VCC
60
mA
LVCMOS/LVTTL DC Electrical Characteristics
(4)
VCC = 3.3V ±5%; TA = -40°C to +85°C, unless otherwise stated.
Symbol
Parameter
Condition
Min
Typ
Max
Units
VIH
Input High Voltage
2
VCC + 0.3V
V
VIL
Input Low Voltage
-0.3
0.8
V
CLK, CLK_SEL
VIN = VCC = 3.465V
150
A
IIH
Input High Current
CLK_EN
VIN = VCC = 3.465V
5
A
CLK, CLK_SEL
VIN = 0V, VCC = 3.465V
-5
A
IIL
Input Low Current
CLK_EN
VIN = 0V, VCC = 3.465V
-150
A
LVPECL DC Electrical Characteristics
(4)
VCC = 3.3V ±5%; TA = -40°C to +85°C, unless otherwise stated.
Symbol
Parameter
Condition
Min
Typ
Max
Units
VOH
Output High Voltage
(5)
VCC - 1.4
VCC – 0.9
V
VOL
Output Low Voltage
(5)
VCC – 2.0
VCC - 1.7
V
VSWING
Peak-to-Peak Output Voltage
Swing
0.6
1.0
V
Notes:
1. Permanent device damage may occur if absolute maximum ratings are exceeded. This is a stress rating only and functional operation is not implied
at conditions other than those detailed in the operational sections of this data sheet. Exposure to absolute maximum rating conditions for extended
periods may affect device reliability.
2. The data sheet limits are not guaranteed if the device is operated beyond the operating ratings.
3.
θJA value is determined for a 4-layer board in still air unless otherwise stated.
4. The circuit is designed to meet the DC specifications shown in the above table after thermal equilibrium has been established.
5. 50 to VCC-2V terminated outputs.
