參數資料
型號： SY89113UMY
廠商： Micrel Inc
文件頁數： 1/14頁
文件大?。?/td> 0K
描述： IC CLK BUFF MUX 2:12 1GHZ 44-MLF
標準包裝： 260
系列： Precision Edge®
類型： 扇出緩沖器（分配），多路復用器
電路數： 1
比率 - 輸入:輸出： 2:12
差分 - 輸入:輸出： 是/是
輸入： CML，CMOS，HSTL，LVDS，LVPECL，TTL
輸出： LVDS
頻率 - 最大： 1GHz
電源電壓： 2.375 V ~ 2.625 V
工作溫度： -40°C ~ 85°C
安裝類型： 表面貼裝
封裝/外殼： 44-VFQFN 裸露焊盤，44-MLF?
供應商設備封裝： 44-MLF?（7x7）
包裝： 管件
產品目錄頁面： 1083 (CN2011-ZH PDF)
其它名稱： 576-3236
SY89113U
2.5V Low Jitter, Low Skew 1:12 LVDS
Fanout Buffer with 2:1 Input MUX and
Internal Termination
Precision Edge is a registered trademark of Micrel, Inc.
Micrel Inc. 2180 Fortune Drive San Jose, CA 95131 USA tel +1 (408) 944-0800 fax + 1 (408) 474-1000 http://www.micrel.com
Oct. 1, 2013
M9999-120607
hbwhelp@micrel.com or (408) 955-1690
General Description
The SY89113U is a 2.5V low jitter, low skew, 1:12
LVDS fanout buffer optimized for precision telecom
and enterprise server distribution applications. The
input includes a 2:1 MUX for clock switchover
applications. Unlike other multiplexers, this input
includes a unique isolation design that minimizes
channel-to-channel
crosstalk.
The
SY89113U
distributes clock frequencies from DC to >1GHz
guaranteed
over
temperature
and
voltage.
The
SY89113U incorporates a synchronous output enable
(EN) so that the outputs will only be enabled/disabled
when they are already in the LOW state.
CLK0 differential input includes Micrel's unique, 3-pin
input termination architecture that directly interfaces to
any differential signal (AC- or DC-coupled) as small as
100mV (200mVPP) without any level shifting or
termination resistor networks in the signal path.
CLK1 differential input includes a new version of
Micrel's unique, Any-Input architecture that directly
interfaces
with
single-ended
TTL/CMOS
logic
(including
3.3V
logic),
single-ended
LVPECL,
differential (AC- or DC-coupled) LVDS, HSTL, CML,
and LVPECL logic levels as small as 200mV
(400mVPP). CLK1 input requires external termination.
LVDS output swing 325mV into 100 with extremely
fast rise/fall time guaranteed to be less than 250ps.
The SY89113U operates from a 2.5V±5% supply and
is guaranteed over the full industrial temperature
range of -40°C to +85°C. The SY89113U is part of
Micrel's high-speed, Precision Edge
product line.
All support documentation can be found
on Micrel’s
web site at: www.micrel.com.
Precision Edge
Features
Selects between 1 of 2 inputs, and provides 12
precision, low skew LVDS output copies
Guaranteed AC performance over temperature and
voltage:
– DC to >1GHz throughput
– <975ps propagation delay CLK0-to-Q
– <250ps rise/fall time
– <25ps output-to-output skew
Ultra-low jitter design:
– 130fs RMS phase jitter (Typ)
– 0.7ps
RMS crosstalk induced jitter
Unique, patent-pending 2:1 input MUX provides
superior isolation to minimize channel-to-channel
crosstalk
CLK0 input features a unique, patent-pending input
termination and VT pin that accepts AC- and DC-
coupled inputs (CML, LVPECL, LVDS)
CLK1 accepts virtually any logic standard:
– Single-ended: TTL/CMOS (including 3.3V logic),
LVPECL
– Differential: LVPECL, LVDS, CML, HSTL
325mV LVDS-compatible output swing
Power supply: 2.5V +5%
Industrial temperature range –40°C to +85°C
Available in 44-pin (7mm x 7mm) QFN package
Applications
Multi-processor server
SONET/SDH clock/data distribution
Fibre Channel distribution
Gigabit Ethernet clock distribution
