參數資料
| 型號： | SWAK0H |
| 廠商： | SEOUL SEMICONDUCTOR CO LTD |
| 元件分類： | LED |
| 英文描述： | SINGLE COLOR LED, WHITE, 2.3 mm |
| 封裝： | 3.80 X 0.95 MM, 0.50 MM HEIGHT, ROHS COMPLIANT, SMT, 2 PIN |
| 文件頁數： | 10/15頁 |
| 文件大?。?/td> | 921K |
| 代理商： | SWAK0H |
Rev. 1.00
SWAF0H
3. Absolute Maximum Ratings
(
Ta = 25°C)
Parameter
Symbol
Value
Unit
Power Dissipation
Pd*1
120
mW
Forward Current
IF
30
mA
Peak Forward Current
IFM*2
100
mA
Reverse Voltage
VR
5
V
Operating Temperature
Topr
-30 ~ +85
°C
Storage Temperature
Tstg
-40 ~ +100
°C
Junction Temperature
Tj
125
°C
*1 Care is to be taken that Power Dissipation does not exceed the Absolute Maximum Rating of the product.
*2
IFM conditions : Pulse width TW ≤ 0.1ms, Duty ratio ≤ 1/10
4. Electro-Optical Characteristics
(
Ta = 25°C)
Item
Symbol
Condition
Min
Typ
Max
Unit
Rank Y
2.7
-
3.0
Rank Z
3.0
-
3.3
Forward Voltage*
Rank A
VF
IF = 20 mA
3.3
-
3.7
V
Reverse Current
IR
VR = 5 V
-
50
A
Rank J3
1300
-
1400
Rank J4
1400
-
1500
Rank J5
1500
-
1600
Luminous Intensity*1
Rank J6
IV
IF = 20 mA
1600
-
1700
mcd
Viewing Angle *2
2
θ1/2
IF = 20 mA
120
x
0.264
-
0.296
Rank b
y
0.248
-
0.295
x
0.287
-
0.311
Rank e
y
0.276
-
0.315
x
0.307
-
0.330
Color Coordinates *3
Rank f
y
IF = 20 mA
0.294
-
0.339
*1 luminous intensity
IV is measured at the peak of the spatial pattern which may not be aligned with the mechanical axis of the LED
package. Luminous Intensity Measurement allowance is ±10%.
*2
θ1/2 is the off-axis where the luminous intensity is 1/2 of the peak intensity.
*3 Measurement Uncertainty of the Color Coordinates is ±0.01
*
Note : All products confirm to the listed minimum and maximum specifications for electric and optical characteristics, when operated at
20mA within the maximum ratings shown above.
All measurements were made under the standardized environment of Seoul Semiconductor.
SEOUL SEMICONDUCTOR CO., LTD.
3
SSC-QP-7-03-44()
