1/8
PRELIMINARY DATA
September 2002
STD38NH02L - STD38NH02L-1
N-CHANNEL 20V - 0.011
- 38A DPAK/IPAK
STripFET
III POWER MOSFET
(1) Starting T
j
=25
°
C, I
D
=19A, V
DD
=18V
I
TYPICAL R
DS
(on) = 0.011
@ 10 V
I
R
DS(ON)
* Q
g
INDUSTRY’s BENCHMARK
I
CONDUCTION LOSSES REDUCED
I
SWITCHING LOSSES REDUCED
I
ADD SUFFIX “T4” FOR ORDERING IN TAPE &
REEL
DESCRIPTION
The
STD38NH02L
utilizes the latest advanced de-
sign rules of ST’s proprietary STripFET
technolo-
gy. This is suitable fot the most demanding DC-DC
converter application where high efficiency is to be
achieved.
APPLICATIONS
I
SPECIFICALLY DESIGNED AND OPTIMISED
FOR HIGH EFFICIENCY DC/DC CONVERTERS
ABSOLUTE MAXIMUM RATINGS
Symbol
V
DS
Drain-source Voltage (V
GS
= 0)
V
DGR
Drain-gate Voltage (R
GS
= 20 k
)
V
GS
Gate- source Voltage
I
D
Drain Current (continuous) at T
C
= 25
°
C
I
D
Drain Current (continuous) at T
C
= 100
°
C
I
DM
(
l
)
Drain Current (pulsed)
P
TOT
Total Dissipation at T
C
= 25
°
C
Derating Factor
(
G
) Pulse width limited by safe operating area
TYPE
V
DSS
R
DS(on)
I
D
STD38NH02L
20 V
<0.0135
38 A
STD38NH02L-1
20 V
<0.0135
38 A
Parameter
Value
Unit
20
V
20
V
±
20
V
38
A
27
A
152
A
40
W
0.27
W/
°
C
mJ
E
AS
(1)
T
stg
T
j
Single Pulse Avalanche Energy
250
Storage Temperature
– 55 to 175
°
C
Max. Operating Junction Temperature
DPAK
1
3
3
2
1
IPAK
INTERNAL SCHEMATIC DIAGRAM
