參數資料
型號: SL18861DIT
廠商: Silicon Laboratories Inc
文件頁數: 7/12頁
文件大?。?/td> 0K
描述: IC CLOCK BUFFER TCXO 10TDFN
標準包裝: 3,000
類型: 扇出緩沖器(分配)
電路數: 1
比率 - 輸入:輸出: 1:3
差分 - 輸入:輸出: 無/無
輸入: LVCMOS
輸出: LVCMOS
頻率 - 最大: 52MHz
電源電壓: 1.7 V ~ 3.65 V
工作溫度: -40°C ~ 85°C
安裝類型: *
封裝/外殼: *
供應商設備封裝: *
包裝: *
Rev 1.2, December 21 , 2010
Page 4 of 12
SL18861DI
AC Electrical Characteristics (I-Grade)
Unless otherwise stated VDD= 1.8V+/- 5% and Operation Temperature Range -40 to +85°C
Parameter
Symbol
Condition
Min
Typ
Max
Unit
Input Clock Range
CLKIN
External Clock, CMOS square wave
or sine wave
10
26.000
52
MHz
Output Clock Range
CLKOUT
External Clock, CMOS square wave
CLKOUT1/2/3
10
26.000
52
MHz
Input Clock Voltage
Swing Level
VINpp
VDD=1.8V
0.72
1
-
Vpp
Input Duty Cycle
DCIN
CLKIN, Pin 3
30
50
70
%
Output Clock Rise Time
tr
VDD=1.8, CL=10pF, measured from
10 to 90% of VDD, Pins 4, 8, 9 and
10
-
2.0
4.00
ns
Output Clock Fall Time
tf
VDD=1.8, CL=10pF, measured from
10 to 90% of VDD, Pins 4, 8, 9 and
10
-
2.0
4.00
ns
Additive Phase Noise
APN-1
CLKIN=26MHz and 1 kHz offset
CLKOUT1/2/3
-
-140
-
dBc/Hz
Additive Phase Noise
APN-2
CLKIN=26MHz and 10 kHz offset
CLKOUT1/2/3
-
-150
-
dBc/Hz
Additive Phase Noise
APN-3
CLKIN=26MHz and 100 kHz offset
CLKOUT1/2/3
-
-159
-
dBc/Hz
Power-up Time
tPU
Time duration until CLKOUT1/2/3
frequency reaches valid frequency
after power supply reaches 0.9xVDD
value
-
100
200
ns
Output Enable Time
tOE1
Time from OE raising edge to active
at outputs CLKOUT1/2/3
(Asynchronous)
-
25
-
ns
Output Disable Time
tOD
Time from OE falling edge to Hi-Z at
outputs CLKOUT1/2/3
(Asynchronous)
-
25
-
ns
Output Enable Time
tOE2
Active recovery time from standby
(CLKIN=0 or 1) to active at outputs
CLKOUT1/2/3
-
100
-
ns
