Part #:
Revision:
Sound Level Category
Specifications:
SCE028LA2SP1B
A
Mallory Sonalert Products,Inc.
Sales Outline Drawing
Loud
Sound Level Category
Mode of Operation
Housing Material
Storage Temperature
Slow Pulse @ 1 PPS
2000 ± 500 Hz
Loud
16 to 28 VAC
Voltage Rating
6/6 Nylon, Color: Black
Frequency
Loudness @ 2 FT
Current Draw
85 to 95 dB(A) Typ.
40mA MAX
-40° to +85° C
UL R
i
d
gp
Operating Temperature
Panel Mounting
NEMA 3R,4X, & 12
Weight (Typical)
-40° to +85° C
cUL Recognition
cUL Recognized
Recommended hole size is 1.25"(31.75mm). Thread front will fit standard 30mm(1.181") hole.
Knurled Nut
Used to attach part to panel. The max recommended torque is 10 in-lbs.
1.6 oz (45g)
Approved with use of ACC03.
Please contact factory.
Options
cUL Recognized
Dimensions:
ROHS Compliant
Inches (mm)
