per DMA channel allows system designers to tailor and balance
the latency behavior for each channel in a given application,
adapting to actual conditions.
Comprehensive software support and reference design
The SAA7135 software development kit (SDK) supports a com-
mon code base for VfW and Windows Driver Model (WDM)
architectures, reducing software maintenance and protecting
software investments. The SDK is based on a Component Object
Model (COM) interface; it includes sample code in Visual Basic
and C++ and a description of the interface.
SAA7135 WDM driver support is provided for all DirectShow
-
based applications. A WDM device driver kit (DDK) includes a
plug-and-play driver, capture-driver installations, and documenta-
tion.The SAA7135 WDM driver is WHQL validated and is
supported for Windows
98/ME/2000/XP. The SAA7135 VfW
driver is available for Windows 95/NT4. A BDA-compliant driver
is included for digital TV applications. The SAA7135 also provides
a customAPI enabling development of specialized applications
when publishedWindowsAPIs (WDM orVfW) are insufficient.
A comprehensive SAA713x Reference Design Kit enables system
designers and hardware manufacturers to quickly evaluate
SAA7135 features and develop single, half-size PCI designs for
hybrid TV receivers.The Kit includes:
> a reference PCI card with SAA7135 decoder, analog TV tuner,
32.11-MHz quartz crystal, I
2
C EEPROM
> a board connector plate with TV connector, CVBS and S-Video
inputs, audio input (line-in) and output (line-out)
> an optional voltage regulator for improved video performance
> the SAA7135 SDK and DDK
> installation and user guides
> board design, schematics, and Gerber files
> video cables
Technical specifications
PHYSICAL
Package
Power
Rectangular LQFP128; 128 pins
supply
3.3 V
consumption
1.35 W (typical application)
0 to 70 oC
Temperature
STANDARD COMPLIANCE/CERTIFICATION
PC
Meets Microsoft/Intel requirements for PC Design
Guides 98/99 and 2001
PCI 2.2 and ACPI compliance (all 4 states)
ANALOG VIDEO SUBSYSTEM
Input
Five (5) analog input ports supporting any combination
of CVBS (NTSC, PAL, SECAM), S-Video
Two (2) 9-bit CMOS ADCs, 27-MHz oversampling
via PCI
YCbCr or RGB including packet and planar,
gamma-compensated, or black stretched
via digital video port(GPIO)
ITU-656, YUV-VMI (8-bit),
VIP 1.1 or VIP 2.0 (8- or 16-bit), ZV (16-bit),
ITU-601 (16-bit)
720 pixels/line (ITU 601)
32.11 or 24.576 MHz, supports all video standards
NTSC/PAL adaptive 4-line Y-C separation for all sources
including broadcast and VCR
Downscaling: horizontal, vertical, and by field rate
Scalable from 10 taps H (for ratios close to 1:1) to 74
taps (icon-sized video)
formats
Closed Captioning,Teletext, NABST, CGMS,
WST, and WSS
PCI output
DMA writes to memory; dedicated channel
with independent sample rate, adjustable by slicing
algorithm
3-level with active status interrupt; complies with
Macrovision’s Copy Protection Detect Specification,
Revision 1.00
ADCs
Output
Sample rate
XTAL reference
Comb filter
Scaling
VBI
Macrovision
