STEP-UP, PWM CONTROL or PWM / PFM SWITCHABLE BUILT-IN TRANSISTOR SWITCHING REGULATOR
Rev.3.0_00
S-8353/8354 Series
Seiko Instruments Inc.
3
Product Name Structure
The control system, product types, output voltage, and packages for the S-8353/8354 Series can be selected at the
user’s request.
Please refer to the “3.
Product Name” for the definition of the product name, “4.
Package” regarding
the package drawings and “5.
Product Name List” for the full product names.
1.
Function List
(1) PWM Control Products
Table 1
Product Name
Switching
Frequency
[kHz]
Shutdown
Function
VDD / VOUT
Separate
Type
Package
Application
S-8353AxxMC
50
Yes
SOT-23-5
Applications requiring shutdown function
S-8353AxxMA
50
SOT-23-3
Applications not requiring shutdown function
S-8353AxxUA
50
SOT-89-3
Applications not requiring shutdown function
S-8353CxxMA
30
SOT-23-3
For pager
S-8353CxxUA
30
SOT-89-3
For pager
S-8353DxxMC
50
Yes
SOT-23-5
Applications requiring variable output voltage
with an external resistor
S-8353HxxMC
250
Yes
SOT-23-5
Applications requiring a shutdown function
and a thin coil
S-8353HxxMA
250
SOT-23-3
Applications not requiring a shutdown function
and requiring a thin coil
S-8353HxxUA
250
SOT-89-3
Applications not requiring a shutdown function
and requiring a thin coil
S-8353JxxMC
250
Yes
SOT-23-5
Applications requiring variable output voltage
with an external resistor and a thin coil
(2) PWM / PFM Switching Control Products
Table 2
Product Name
Switching
Frequency
[kHz]
Shutdown
Function
VDD / VOUT
Separate
Type
Package
Application
S-8354AxxMC
50
Yes
SOT-23-5
Applications requiring shutdown function
S-8354AxxMA
50
SOT-23-3
Applications not requiring shutdown function
S-8354AxxUA
50
SOT-89-3
Applications not requiring shutdown function
S-8354CxxMA
30
SOT-23-3
For pager
S-8354DxxMC
50
Yes
SOT-23-5
Applications requiring variable output voltage
with an external resistor
S-8354HxxMC
250
Yes
SOT-23-5
Applications requiring a shutdown function
and a thin coil
S-8354HxxMA
250
SOT-23-3
Applications not requiring a shutdown function
and requiring a thin coil
S-8354HxxUA
250
SOT-89-3
Applications not requiring a shutdown function
and requiring a thin coil
S-8354JxxMC
250
Yes
SOT-23-5
Applications requiring variable output voltage
with an external resistor and a thin coil
